– 82 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< COIL >
L111 1-414-146-31 INDUCTOR 2.2uH
L112 1-414-146-31 INDUCTOR 2.2uH
L211 1-414-146-31 INDUCTOR 2.2uH
L212 1-414-146-31 INDUCTOR 2.2uH
L311 1-410-750-41 INDUCTOR 0.47uH
L312 1-410-750-41 INDUCTOR 0.47uH
*************************************************************
* 1-671-072-11 LOADING BOARD
**************
< CAPACITOR >
C651 1-104-664-11 ELECT 47uF 20% 10V
< CONNECTOR >
* CN651 1-580-167-11 PIN, CONNECTOR (PC BOARD) 6P
< IC >
IC651 8-759-962-08 IC BA6208
< SWITCH >
S651 1-771-489-11 SWITCH, LEVER SLIDE (LOADING IN/OUT DET)
*************************************************************
* A-3322-764-A MAIN BOARD, COMPLETE
*********************
7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
< CAPACITOR >
C113 1-127-880-21 CERAMIC 0.022uF 10% 50V
C114 1-126-960-11 ELECT 1uF 20% 50V
C115 1-126-960-11 ELECT 1uF 20% 50V
C116 1-126-960-11 ELECT 1uF 20% 50V
C117 1-126-960-11 ELECT 1uF 20% 50V
C118 1-126-963-11 ELECT 4.7uF 20% 50V
C119 1-126-964-11 ELECT 10uF 20% 50V
C120 1-130-475-00 MYLAR 0.0022uF 5% 50V
C121 1-136-495-11 MYLAR 0.068uF 5% 50V
C122 1-136-495-11 MYLAR 0.068uF 5% 50V
C123 1-136-169-00 MYLAR 0.22uF 5% 50V
C124 1-136-169-00 MYLAR 0.22uF 5% 50V
C125 1-104-665-11 ELECT 100uF 20% 10V
C126 1-126-963-11 ELECT 4.7uF 20% 50V
C127 1-126-960-11 ELECT 1uF 20% 50V
C128 1-162-294-31 CERAMIC 0.001uF 10% 50V
C129 1-104-664-11 ELECT 47uF 20% 10V
C130 1-104-664-11 ELECT 47uF 20% 10V
C131 1-162-282-31 CERAMIC 100PF 10% 50V
C132 1-162-282-31 CERAMIC 100PF 10% 50V
C133 1-162-282-31 CERAMIC 100PF 10% 50V
C134 1-162-282-31 CERAMIC 100PF 10% 50V
C135 1-162-282-31 CERAMIC 100PF 10% 50V
C213 1-127-880-21 CERAMIC 0.022uF 10% 50V
C214 1-126-960-11 ELECT 1uF 20% 50V
C215 1-126-960-11 ELECT 1uF 20% 50V
C216 1-126-960-11 ELECT 1uF 20% 50V
C217 1-126-960-11 ELECT 1uF 20% 50V
C218 1-126-963-11 ELECT 4.7uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C220 1-130-475-00 MYLAR 0.0022uF 5% 50V
C221 1-136-495-11 MYLAR 0.068uF 5% 50V
C222 1-136-495-11 MYLAR 0.068uF 5% 50V
C223 1-136-169-00 MYLAR 0.22uF 5% 50V
C224 1-136-169-00 MYLAR 0.22uF 5% 50V
C225 1-104-665-11 ELECT 100uF 20% 10V
C226 1-126-963-11 ELECT 4.7uF 20% 50V
C227 1-126-960-11 ELECT 1uF 20% 50V
C228 1-162-294-31 CERAMIC 0.001uF 10% 50V
C229 1-104-664-11 ELECT 47uF 20% 10V
C230 1-104-664-11 ELECT 47uF 20% 10V
C231 1-162-282-31 CERAMIC 100PF 10% 50V
C232 1-162-282-31 CERAMIC 100PF 10% 50V
C233 1-162-282-31 CERAMIC 100PF 10% 50V
C234 1-162-282-31 CERAMIC 100PF 10% 50V
C235 1-162-282-31 CERAMIC 100PF 10% 50V
C313 1-127-880-21 CERAMIC 0.022uF 10% 50V
C314 1-162-292-31 CERAMIC 680PF 10% 50V
C315 1-124-252-00 ELECT 0.33uF 20% 50V
C316 1-126-962-11 ELECT 3.3uF 20% 50V
C317 1-126-961-11 ELECT 2.2uF 20% 50V
C318 1-126-964-11 ELECT 10uF 20% 50V
C319 1-126-963-11 ELECT 4.7uF 20% 50V
C320 1-127-888-21 CERAMIC 0.1uF 10% 50V
C321 1-104-665-11 ELECT 100uF 20% 10V
C322 1-104-664-11 ELECT 47uF 20% 10V
C323 1-127-888-21 CERAMIC 0.1uF 10% 50V
C324 1-162-282-31 CERAMIC 100PF 10% 50V
C325 1-162-282-31 CERAMIC 100PF 10% 50V
C326 1-126-963-11 ELECT 4.7uF 20% 50V
C327 1-126-934-11 ELECT 220uF 20% 10V
C329 1-126-964-11 ELECT 10uF 20% 50V
C351 1-104-665-11 ELECT 100uF 20% 10V
C352 1-161-494-00 CERAMIC 0.022uF 25V
C353 1-126-924-11 ELECT 330uF 20% 10V
C354 1-104-664-11 ELECT 47uF 20% 10V
C355 1-104-665-11 ELECT 100uF 20% 10V
C356 1-162-306-11 CERAMIC 0.01uF 20% 16V
C357 1-104-665-11 ELECT 100uF 20% 10V
C358 1-161-494-00 CERAMIC 0.022uF 25V
C359 1-126-964-11 ELECT 10uF 20% 50V
C360 1-126-382-11 ELECT 100uF 20% 16V
C361 1-104-664-11 ELECT 47uF 20% 10V
C362 1-162-306-11 CERAMIC 0.01uF 20% 16V
C363 1-162-306-11 CERAMIC 0.01uF 20% 16V
LINE LOADING MAIN
