– 85 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* CNP902 1-691-580-11 PIN, CONNECTOR (PC BOARD) 9P
* CNP903 1-564-507-11 PLUG, CONNECTOR 4P
< DIODE >
D901 8-719-046-47 DIODE 1N5401TM
D902 8-719-046-47 DIODE 1N5401TM
D903 8-719-046-47 DIODE 1N5401TM
D904 8-719-046-47 DIODE 1N5401TM
D905 8-719-991-33 DIODE 1SS133T-77
D906 8-719-063-79 DIODE 1N4002B
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-991-33 DIODE 1SS133T-77
D911 8-719-109-93 DIODE RD6.2ESB2
D912 8-719-983-38 DIODE MTZJ-T-77-36B
< IC >
IC311 8-759-333-16 IC LA4705NA
< JACK >
J321 1-770-612-12 JACK, PIN 2P (SIGNAL IN L/R)
< COIL >
L502 1-410-509-11 INDUCTOR 10uH
L503 1-410-509-11 INDUCTOR 10uH
< LINE FILTER >
0LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< TRANSISTOR >
Q901 8-729-036-89 TRANSISTOR KTC3198GR-AT
Q902 8-729-037-34 TRANSISTOR KRA107M
Q903 8-729-036-77 TRANSISTOR KRC107M
Q904 8-729-037-13 TRANSISTOR KTA1271Y
Q905 8-729-036-77 TRANSISTOR KRC107M
Q906 8-729-036-77 TRANSISTOR KRC107M
Q907 8-729-037-34 TRANSISTOR KRA107M
Q908 8-729-036-77 TRANSISTOR KRC107M
Q909 8-729-037-34 TRANSISTOR KRA107M
Q910 8-729-012-83 FET 2SK679A
Q911 8-729-012-83 FET 2SK679A
Q912 8-729-036-58 TRANSISTOR KRC102M-AT
Q913 8-729-037-34 TRANSISTOR KRA107M
< RESISTOR >
R181 1-249-425-11 CARBON 4.7K 5% 1/4W
R182 1-247-851-11 CARBON 6.8K 5% 1/4W
R183 1-249-385-11 CARBON 2.2 5% 1/6W
R184 1-249-385-11 CARBON 2.2 5% 1/6W
R281 1-249-425-11 CARBON 4.7K 5% 1/4W
R282 1-247-851-11 CARBON 6.8K 5% 1/4W
R283 1-249-385-11 CARBON 2.2 5% 1/6W
R284 1-249-385-11 CARBON 2.2 5% 1/6W
R381 1-249-425-11 CARBON 4.7K 5% 1/4W
R383 1-249-417-11 CARBON 1K 5% 1/4W
R502 1-249-421-11 CARBON 2.2K 5% 1/4W
R503 1-249-421-11 CARBON 2.2K 5% 1/4W
R901 1-249-427-11 CARBON 6.8K 5% 1/4W
R902 1-247-807-31 CARBON 100 5% 1/4W
R903 1-247-739-11 CARBON 100 5% 1/2W
R904 1-247-891-00 CARBON 330K 5% 1/4W
R905 1-247-891-00 CARBON 330K 5% 1/4W
R906 1-249-431-11 CARBON 15K 5% 1/4W
R907 1-249-441-11 CARBON 100K 5% 1/4W
R908 1-247-895-11 CARBON 470K 5% 1/4W
R909 1-249-441-11 CARBON 100K 5% 1/4W
R910 1-247-895-11 CARBON 470K 5% 1/4W
R911 1-249-417-11 CARBON 1K 5% 1/4W
< RELAY >
0RY901 1-755-386-11 RELAY
*************************************************************
* 1-677-027-11 SPEAKER BOARD
**************
< CONNECTOR >
* CNP911 1-564-505-11 PLUG, CONNECTOR 2P
< TERMINAL >
J901 1-536-707-21 TERMINAL, PUSH (2P) (SPEAKER OUTPUT
R-CH)
*************************************************************
* A-3322-501-A TC BOARD, COMPLETE
*******************
< CAPACITOR >
C101 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C103 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C104 1-104-664-11 ELECT 47uF 20% 10V
C105 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C106 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C107 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
C108 1-126-959-11 ELECT 0.47uF 20% 50V
C110 1-126-960-11 ELECT 1uF 20% 50V
C111 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C201 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C203 1-163-139-00 CERAMIC CHIP 820PF 5% 50V
C204 1-104-664-11 ELECT 47uF 20% 10V
C205 1-162-587-11 CERAMIC CHIP 0.039uF 10% 25V
C206 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C207 1-163-109-00 CERAMIC CHIP 47PF 5% 50V
POWER SPEAKER
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
TC
To Next Page
