– 86 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C208 1-126-959-11 ELECT 0.47uF 20% 50V
C210 1-126-960-11 ELECT 1uF 20% 50V
C211 1-163-001-11 CERAMIC CHIP 220PF 10% 50V
C301 1-104-665-11 ELECT 100uF 20% 10V
C302 1-126-925-11 ELECT 470uF 20% 10V
C303 1-104-665-11 ELECT 100uF 20% 10V
C304 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C305 1-130-485-00 MYLAR 0.015uF 5% 50V
C306 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C307 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C308 1-104-664-11 ELECT 47uF 20% 10V
C309 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C310 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C311 1-163-033-11 CERAMIC CHIP 0.022uF 50V
C312 1-163-033-11 CERAMIC CHIP 0.022uF 50V
C391 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
< CONNECTOR >
CNP301 1-580-168-11 PIN, CONNECTOR (PC BOARD) 7P
* CNP302 1-766-594-11 PIN, CONNECTOR (PC BOARD) 11P
< DIODE >
D301 8-719-988-61 DIODE 1SS355TE-17
D302 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC301 8-759-264-71 IC TA2068N
< JUMPER RESISTOR >
JR101 1-216-295-00 SHORT 0
JR102 1-216-295-00 SHORT 0
JR103 1-216-295-00 SHORT 0
JR104 1-216-295-00 SHORT 0
JR105 1-216-295-00 SHORT 0
JR106 1-216-295-00 SHORT 0
JR107 1-216-295-00 SHORT 0
JR108 1-216-295-00 SHORT 0
JR109 1-216-295-00 SHORT 0
JR110 1-216-295-00 SHORT 0
JR111 1-216-295-00 SHORT 0
JR113 1-216-295-00 SHORT 0
JR114 1-216-295-00 SHORT 0
< TRANSISTOR >
Q301 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q302 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q303 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q304 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q305 8-729-900-53 TRANSISTOR DTC114EK
Q306 8-729-900-53 TRANSISTOR DTC114EK
Q307 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q308 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q309 8-729-900-53 TRANSISTOR DTC114EK
Q310 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q311 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q334 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-077-11 RES-CHIP 15K 5% 1/10W
R102 1-216-019-00 METAL CHIP 56 5% 1/10W
R103 1-216-097-11 RES-CHIP 100K 5% 1/10W
R104 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R105 1-216-025-11 RES-CHIP 100 5% 1/10W
R106 1-216-049-11 RES-CHIP 1K 5% 1/10W
R107 1-216-025-11 RES-CHIP 100 5% 1/10W
R108 1-216-033-00 METAL CHIP 220 5% 1/10W
R109 1-216-033-00 METAL CHIP 220 5% 1/10W
R201 1-216-077-11 RES-CHIP 15K 5% 1/10W
R202 1-216-019-00 METAL CHIP 56 5% 1/10W
R203 1-216-097-11 RES-CHIP 100K 5% 1/10W
R204 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R205 1-216-025-11 RES-CHIP 100 5% 1/10W
R206 1-216-049-11 RES-CHIP 1K 5% 1/10W
R207 1-216-025-11 RES-CHIP 100 5% 1/10W
R208 1-216-033-00 METAL CHIP 220 5% 1/10W
R209 1-216-033-00 METAL CHIP 220 5% 1/10W
R301 1-216-121-11 RES-CHIP 1M 5% 1/10W
R302 1-216-017-11 RES-CHIP 47 5% 1/10W
R303 1-216-073-00 METAL CHIP 10K 5% 1/10W
R304 1-216-073-00 METAL CHIP 10K 5% 1/10W
R305 1-216-073-00 METAL CHIP 10K 5% 1/10W
R306 1-216-073-00 METAL CHIP 10K 5% 1/10W
R307 1-216-097-11 RES-CHIP 100K 5% 1/10W
R308 1-216-097-11 RES-CHIP 100K 5% 1/10W
R309 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
R310 1-216-073-00 METAL CHIP 10K 5% 1/10W
R311 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R312 1-216-093-11 RES-CHIP 68K 5% 1/10W
R313 1-216-017-11 RES-CHIP 47 5% 1/10W
R314 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R315 1-216-049-11 RES-CHIP 1K 5% 1/10W
R316 1-216-049-11 RES-CHIP 1K 5% 1/10W
R317 1-216-049-11 RES-CHIP 1K 5% 1/10W
R318 1-216-065-11 RES-CHIP 4.7K 5% 1/10W
< TRANSFORMER >
T301 1-429-820-11 TRANSFORMER, BIAS OSCILLATION
*************************************************************
* 1-673-338-11 TC RF BOARD
***********
< CONNECTOR >
* CNP314 1-580-170-11 PIN, CONNECTOR (PC BOARD) 9P
TC TC RF
