Sony PMC-DR45 - Tuner Electrical Parts

– 87 –
< PHOTO INTERRUPTER >
PH691 8-719-078-47 PHOTO INTERRUPTER SG-211V
< RESISTOR >
R691 1-249-441-11 CARBON 100K 5% 1/4W
< SWITCH >
S691 1-771-893-11 MODE (SW) (HEAD POSITION)
S692 1-771-661-11 SWITCH, LEAF (HALF DET)
S693 1-771-661-11 SWITCH, LEAF (CrO2)
S694 1-771-661-11 SWITCH, LEAF (FWD ERASE PROOF)
S695 1-771-661-11 SWITCH, LEAF (REV ERASE PROOF)
*************************************************************
* 1-677-030-11 TOP BOARD
**********
< CABLE HOLDER >
* KH811 1-565-384-11 HOLDER, CABLE 3P
< RESISTOR >
R421 1-249-413-11 CARBON 470 5% 1/4W
R422 1-249-412-11 CARBON 390 5% 1/4W
R423 1-249-413-11 CARBON 470 5% 1/4W
R424 1-249-413-11 CARBON 470 5% 1/4W
R425 1-249-415-11 CARBON 680 5% 1/4W
R426 1-249-415-11 CARBON 680 5% 1/4W
R427 1-249-417-11 CARBON 1K 5% 1/4W
R428 1-249-418-11 CARBON 1.2K 5% 1/4W
R429 1-249-419-11 CARBON 1.5K 5% 1/4W
R430 1-249-421-11 CARBON 2.2K 5% 1/4W
R431 1-247-843-11 CARBON 3.3K 5% 1/4W
R432 1-249-413-11 CARBON 470 5% 1/4W
R433 1-249-412-11 CARBON 390 5% 1/4W
R434 1-249-413-11 CARBON 470 5% 1/4W
R435 1-249-413-11 CARBON 470 5% 1/4W
R436 1-249-415-11 CARBON 680 5% 1/4W
R437 1-249-415-11 CARBON 680 5% 1/4W
< SWITCH >
S801 1-762-798-11 SWITCH, KEY BOARD (LINE)
S802 1-762-798-11 SWITCH, KEY BOARD (TAPE N)
S803 1-762-798-11 SWITCH, KEY BOARD (TAPE n)
S804 1-762-798-11 SWITCH, KEY BOARD (TAPE x)
S805 1-762-798-11 SWITCH, KEY BOARD (CD DUBBING)
S806 1-762-798-11 SWITCH, KEY BOARD (z REC)
S807 1-762-798-11 SWITCH, KEY BOARD (m)
S808 1-762-798-11 SWITCH, KEY BOARD (M)
S809 1-762-798-11 SWITCH, KEY BOARD (./TUNING TIME SET –)
S810 1-762-798-11 SWITCH, KEY BOARD (>/TUNING TIME SET +)
S811 1-762-798-11 SWITCH, KEY BOARD (RDS)
S812 1-762-798-11 SWITCH, KEY BOARD (CD x)
S813 1-762-798-11 SWITCH, KEY BOARD (CD u)
S814 1-762-798-11 SWITCH, KEY BOARD (PRESET –)
S815 1-762-798-11 SWITCH, KEY BOARD (BAND AUTO PRESET)
S816 1-762-798-11 SWITCH, KEY BOARD (PRESET +)
S817 1-762-798-11 SWITCH, KEY BOARD (SNOOZE)
*************************************************************
* A-3323-552-A TUNER BOARD, COMPLETE
**********************
< CAPACITOR >
C1 1-163-011-11 CERAMIC CHIP 0.0015uF 10% 50V
C2 1-126-960-11 ELECT 1uF 20% 50V
C3 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C4 1-126-963-11 ELECT 4.7uF 20% 50V
C5 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C6 1-163-037-00 CERAMIC CHIP 0.022uF 5% 50V
C7 1-163-037-00 CERAMIC CHIP 0.022uF 5% 50V
C8 1-126-934-11 ELECT 220uF 20% 10V
C9 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C10 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C11 1-163-231-11 CERAMIC CHIP 15PF 5% 50V
C12 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C13 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C14 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C15 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C16 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C17 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C18 1-163-103-11 CERAMIC CHIP 27PF 5% 50V
C19 1-126-960-11 ELECT 1uF 20% 50V
C20 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C21 1-163-003-11 CERAMIC CHIP 330PF 10% 50V
C22 1-126-960-11 ELECT 1uF 20% 50V
C23 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C24 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C25 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C26 1-163-021-11 CERAMIC CHIP 0.001uF 10% 50V
C27 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C28 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C29 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C30 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C31 1-163-227-11 CERAMIC CHIP 10PF 0.5PF 50V
C32 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C33 1-104-665-11 ELECT 100uF 20% 10V
C34 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C35 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C36 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C37 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C38 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C40 1-136-171-00 MYLAR 0.33uF 5% 50V
C41 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C44 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C45 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C46 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TC RF TOP TUNER
