– 88 –
C47 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C48 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C49 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
< FILTER >
CF2 1-760-738-61 FILTER, CERAMIC
CF3 1-760-738-61 FILTER, CERAMIC
CF4 1-781-344-12 FILTER, AM CERAMIC
< CONNECTOR >
* CNP1 1-766-594-11 PIN, CONNECTOR (PC BOARD) 11P
< TRIMMER >
CT1 1-141-227-00 TRIMMER, CERAMIC 20PF
CT3 1-141-410-11 CAP, ADJ 10PF
< DIODE >
D1 8-719-988-61 DIODE 1SS355TE-17
D2 8-719-988-61 DIODE 1SS355TE-17
D3 8-719-050-69 DIODE KV1520N
D4 8-719-076-71 DIODE KV1471ETR
D5 8-719-076-71 DIODE KV1471ETR
D6 8-719-988-61 DIODE 1SS355TE-17
D7 8-719-988-61 DIODE 1SS355TE-17
< BPF >
FL1 1-236-711-21 FILTER, BAND PASS
< IC >
IC1 8-759-662-67 IC TA2149N
IC2 8-759-483-40 IC LC72137M-TLM
< JUMPER RESISTOR >
JC1 1-216-295-00 SHORT 0
JC2 1-216-295-00 SHORT 0
JC3 1-216-295-00 SHORT 0
JC4 1-216-295-00 SHORT 0
JC5 1-216-295-00 SHORT 0
JC6 1-216-295-00 SHORT 0
JC7 1-216-295-00 SHORT 0
JC8 1-216-295-00 SHORT 0
JC9 1-216-295-00 SHORT 0
JC10 1-216-295-00 SHORT 0
JC11 1-216-295-00 SHORT 0
JC12 1-216-295-00 SHORT 0
JC13 1-216-295-00 SHORT 0
JC14 1-216-295-00 SHORT 0
JC16 1-216-295-00 SHORT 0
JC19 1-216-295-00 SHORT 0
JC22 1-216-295-00 SHORT 0
< COIL >
L1 1-416-533-11 COIL, AIR-CORE
L2 1-416-509-11 COIL, AIR-CORE
< RESISTOR >
R1 1-216-073-00 METAL CHIP 10K 5% 1/10W
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-089-11 RES-CHIP 47K 5% 1/10W
R4 1-216-105-11 RES-CHIP 220K 5% 1/10W
R5 1-216-097-11 RES-CHIP 100K 5% 1/10W
R6 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R7 1-216-077-11 RES-CHIP 15K 5% 1/10W
R8 1-216-001-00 METAL CHIP 10 5% 1/10W
R9 1-216-033-00 METAL CHIP 220 5% 1/10W
R10 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R11 1-216-089-11 RES-CHIP 47K 5% 1/10W
R13 1-216-049-11 RES-CHIP 1K 5% 1/10W
R15 1-216-029-00 METAL CHIP 150 5% 1/10W
R16 1-216-049-11 RES-CHIP 470 5% 1/10W
R17 1-216-049-11 RES-CHIP 470 5% 1/10W
R18 1-216-049-11 RES-CHIP 1K 5% 1/10W
R19 1-216-049-11 RES-CHIP 1K 5% 1/10W
R20 1-216-049-11 RES-CHIP 1K 5% 1/10W
R21 1-216-049-11 RES-CHIP 1K 5% 1/10W
R23 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R24 1-216-049-11 RES-CHIP 1K 5% 1/10W
R25 1-216-081-00 METAL CHIP 22K 5% 1/10W
R26 1-216-073-00 METAL CHIP 10K 5% 1/10W
R27 1-216-075-00 METAL CHIP 12K 5% 1/10W
R28 1-216-043-11 RES-CHIP 560 5% 1/10W
R30 1-216-073-00 METAL CHIP 10K 5% 1/10W
R31 1-216-041-00 METAL CHIP 470 5% 1/10W
R32 1-216-049-11 RES-CHIP 1K 5% 1/10W
R33 1-216-049-11 RES-CHIP 1K 5% 1/10W
< TRANSFORMER >
T1 1-435-333-11 TRANSFORMER, IF
T2 1-419-465-11 COIL (DET)
T3 1-416-251-11 COIL, AM ANT
T4 1-411-234-21 COIL, AM OSC
< TERMINAL >
TM1 1-694-668-11 TERMINAL BOARD (AM,EXT ANT)
< VIBRATOR >
X1 1-781-592-11 VIBRATOR, CRYSTAL (75kHz)
*************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TUNER
