– 89 –
MISCELLANEOUS
***************
* 15 1-792-256-11 CABLE, FLEXIBLE (6P) (MAIN-CD)
* 16 1-792-226-11 CABLE, FFC (15P) (CD-CONT)
* 55 1-792-225-11 CABLE, FFC (31P) (MAIN-CONT)
* 109 1-792-227-11 CABLE, FFC (16P) (CD-PICK UP)
185 1-792-511-11 WIRE (MM)
* 232 1-794-104-11 HOUSING
0251 8-848-483-05 OPTICAL PICK-UP KSS-213C
255 X-2646-381-1 CHASSIS ASSY (MB) (RP), MOTOR (SPINDLE)
(INCLUDING M702)
0308 1-783-531-11 CORD, POWER
314 1-757-050-11 LEAD WIRE (WITH CONNECTOR)
0F901 1-532-501-51 FUSE (0.8A/245V)
0F902 1-532-506-51 FUSE (6.3A/250V)
HRPE3011-418-847-11 HEAD ASSY, HOLDER (REC/PB/ERASE)
M651 A-3320-538-A MOTOR ASSY, LOADING (LOADING)
M691 3-045-799-01 MOTOR ASSY (CAPSTAN/RELL)
(INCLUDING PULLEY)
M701 X-2625-769-1 GEAR ASSY, MOTOR (SLED)
PM691 1-454-896-11 SOLENOID, PLUNGER
SP101 1-529-615-11 SPEAKER (8cm) (L-CH)
SP201 1-529-615-11 SPEAKER (8cm) (R-CH)
0T901 1-435-351-11 TRANSFORMER, POWER
*************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-501-374-11 ANTENNA, LOOP (AM)
1-501-594-51 ANTENNA (FM) (Canadian)
1-501-695-11 ANTENNA (FM) (US)
1-791-562-11 CORD, CONNECTION (AUDIO)
3-027-153-11 LID, BATTERY CASE (for RMT-CDR45A)
3-044-713-71 MANUAL, INSTRUCTION (ENGLISH)
3-044-713-81 MANUAL, INSTRUCTION (ENGLISH,FRENCH)
(Canadian)
A-3258-018-A REMOTE COMMANDER RMT-CDR45A
*************************************************************
**************
HARDWARE LIST
**************
#1 7-685-647-79 SCREW +BVTP 3X10 TYPE2 N-S
#2 7-685-648-14 SCREW +BVTP 3X12 TYPE2 N-S
#3 7-685-134-19 SCREW +BTP 2.6X8 TYPE2 N-S
#4 7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
#5 7-621-283-00 SCREW +P 2X5
#6 7-621-772-00 SCREW +B 2X3
#7 7-682-560-04 SCREW +B 4X6
#8 7-621-843-25 SCREW, WOOD +R 3.1X10
#9 7-685-548-14 SCREW +BTP 3X12 TYPE2 N-S
#10 7-685-647-14 SCREW +BVTP 3X10 TYPE2 N-S
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
To Next Page
