Sony RCD-W10 Service Manual

20
RCD-W10
3 Operation mode
bit 7: Speed
0: normal speed
1: x4 speed
bit 6 to bit 0: Number of inner condition
01: POWER off condition/during shift to POWER on
02: POWER off and shipment setting/during shift to POWER
off and shipment setting
03: stop condition/during stop
04: during start up of servo
05: during TOC reading and others
06: during CD TEXT reading
07: during standby(waiting for command from the CD sys-
tem)/during search
08: during playback
09: during manual search(playback)
0A:during pause
0B:during manual search(pause)
0C:during OPC
0D:recording standby/during recording pause
(enable to shift to recording)
0E: during recording
0F: unable to record (waiting for shift to being recordable)
10: PMA updating
11: during operation of unfinalize
12: during operation of finalize
13: PMA erasing
14: emergency
15: recording preparation
16: recording end
examples :
4 Start time of read in(compression method)
bit 15 to bit 13 : (min)
0: 97 min
1: 96 min
2: 95 min
7: others
bit 12 to bit 7: (sec)
bit 6 to bit 0: (frame)
examples :
0000 1101 1000 0000
0001 0001 0001 0110
0D,80
11,16
7
0(frame)
654 321
34(sec)97(min) 22(frame)
015 14 13 12 11 10 9 8 Start time of read in
97 : 27 : 00
97 : 34 : 22
97(min) 27(sec)
bit
HEX
0000 0111
07
91
1001 0001
7
7
654 321
11 1
0 Operation mode
normal speed, during
standby(waiting for
command from the CD
system)/during search
x4 speed,
during operation of
unfinalize
00
bit
HEX
5 Write POWER (integer of mW x 10, available during write
processing)
examples: 00 means unavailable
(when 3 operation mode is not recording)
: A3 means 163(decimal), i.e. 16.3 mW
6 ATIME (min)/(sec)/(frame)
example: 0E, 2E, 0D means 14 : 46 : 13
Abbreviations:
ATIP : Absolute Time In Pre-groove
OPC : Optimum POWER Control
PMA : Program Memory Area

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
