4-7. NG Message List
Message Cause
Tray OPEN NG! The tray has not opened within the specified time.
Tray Close NG! The tray has not closed within the specified time.
SLEDIN NG! The sled has not moved toward inner circumference within the specified time.
SLEDOUT NG! The sled has not moved toward outer circumference within the specified time.
RIDR NG! The RID information could not be read out within the specified time.
SNread (1) NG! The SN (1) information could not be read out within the specified time.
SNread (2) NG! The SN (2) information could not be read out within the specified time.
SNread (3) NG! The SN (3) information could not be read out within the specified time.
FBIASADJ NG! The Focus Bias Adjustment has not completed within the specified time.
FEOSADJ NG! The FE Offset Adjustment has not completed within the specified time.
FESAMPADJ NG! The FE Amplitude Adjustment has not completed within the specified time.
RFACCHK NG! The RFAC amplitude is abnormal or the adjustment has not completed within the specified time.
RPINWADJ1 NG! The Read Power (during Write1) Adjustment has not completed within the specified time.
RPINWADJ2 NG! The Read Power (during Write2) Adjustment has not completed within the specified time.
SERVOSET NG! The Servo Setting has not completed within the specified time.
TSa NG! The ATIME Search has not completed within the specified time.
PLAYSW NG! The Play operation has not started within the specified time.
STOP NG! The Stop operation has not completed within the specified time.
AMS NG! The AMS operation has not completed within the specified time.
ATIPPLAY NG! The ATIP Play operation has not started within the specified time.
END TNO get NG! The record-end track information could not be obtained within the specified time.
LEADOUT info.get NG! The record-end time information could not be obtained within the specified time.
Invalid EndTrackNo./LeadoutTime ! The illegal record-end track and its time information were obtained.
Use the Blank disc The disc exceeding the allowable limit is used.
DIR unlock! The equipment could not be synchronized with the signal connected to DIN2.
RWP NG! The CD-R Write Power setting has not completed within the specified time.
RWWP NG! The CD-RW Write Power setting has not completed within the specified time.
REC NG! The record operation could not be started within the specified time.

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
