Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
94
RCD-W10
R192 1-216-864-11 METAL CHIP 0 5% 1/16W
R193 1-220-810-11 RES-CHIP 0.39 1% 1/2W
R194 1-216-864-11 METAL CHIP 0 5% 1/16W
R196 1-216-864-11 METAL CHIP 0 5% 1/16W
R198 1-216-864-11 METAL CHIP 0 5% 1/16W
R200 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R201 1-216-864-11 METAL CHIP 0 5% 1/16W
R202 1-216-817-11 METAL CHIP 470 5% 1/16W
R203 1-216-864-11 METAL CHIP 0 5% 1/16W
R204 1-216-864-11 METAL CHIP 0 5% 1/16W
R205 1-216-864-11 METAL CHIP 0 5% 1/16W
R206 1-216-864-11 METAL CHIP 0 5% 1/16W
R207 1-216-813-11 METAL CHIP 220 5% 1/16W
R208 1-216-864-11 METAL CHIP 0 5% 1/16W
R209 1-216-864-11 METAL CHIP 0 5% 1/16W
R210 1-216-864-11 METAL CHIP 0 5% 1/16W
R211 1-216-864-11 METAL CHIP 0 5% 1/16W
R212 1-216-833-11 METAL CHIP 10K 5% 1/16W
R213 1-216-817-11 METAL CHIP 470 5% 1/16W
R215 1-216-864-11 METAL CHIP 0 5% 1/16W
R216 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R217 1-216-864-11 METAL CHIP 0 5% 1/16W
R218 1-216-864-11 METAL CHIP 0 5% 1/16W
R219 1-216-801-11 METAL CHIP 22 5% 1/16W
R220 1-216-801-11 METAL CHIP 22 5% 1/16W
R221 1-216-801-11 METAL CHIP 22 5% 1/16W
R222 1-216-801-11 METAL CHIP 22 5% 1/16W
R223 1-216-864-11 METAL CHIP 0 5% 1/16W
R224 1-216-864-11 METAL CHIP 0 5% 1/16W
R225 1-216-833-11 METAL CHIP 10K 5% 1/16W
R226 1-216-864-11 METAL CHIP 0 5% 1/16W
R227 1-216-797-11 METAL CHIP 10 5% 1/16W
R228 1-216-833-11 METAL CHIP 10K 5% 1/16W
R229 1-216-864-11 METAL CHIP 0 5% 1/16W
R230 1-216-817-11 METAL CHIP 470 5% 1/16W
R231 1-216-809-11 METAL CHIP 100 5% 1/16W
R232 1-216-864-11 METAL CHIP 0 5% 1/16W
R239 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R240 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R241 1-216-809-11 METAL CHIP 100 5% 1/16W
R242 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R243 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R244 1-216-864-11 METAL CHIP 0 5% 1/16W
R245 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R246 1-216-833-11 METAL CHIP 10K 5% 1/16W
R248 1-218-831-11 METAL CHIP 220 0.5% 1/10W
R250 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R251 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R253 1-216-864-11 METAL CHIP 0 5% 1/16W
R254 1-216-857-11 METAL CHIP 1M 5% 1/16W
R258 1-216-833-11 METAL CHIP 10K 5% 1/16W
R260 1-216-833-11 METAL CHIP 10K 5% 1/16W
R262 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R263 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R264 1-216-797-11 METAL CHIP 10 5% 1/16W
R265 1-218-833-11 METAL CHIP 270 0.5% 1/10W
R267 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R268 1-218-864-11 METAL CHIP 5.1K 0.5% 1/10W
R269 1-216-817-11 METAL CHIP 470 5% 1/16W
R270 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R271 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R274 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R276 1-218-843-11 METAL CHIP 680 0.5% 1/10W
R277 1-218-865-11 METAL CHIP 5.6K 0.5% 1/10W
R278 1-218-285-11 RES-CHIP 75 5% 1/10W
R281 1-218-847-11 METAL CHIP 1K 0.5% 1/10W
R283 1-216-809-11 METAL CHIP 100 5% 1/16W
R290 1-216-833-11 METAL CHIP 10K 5% 1/16W
R291 1-216-811-11 METAL CHIP 150 5% 1/16W
R292 1-216-833-11 METAL CHIP 10K 5% 1/16W
R294 1-216-864-11 METAL CHIP 0 5% 1/16W
R300 1-216-833-11 METAL CHIP 10K 5% 1/16W
R301 1-216-845-11 METAL CHIP 100K 5% 1/16W
R302 1-216-845-11 METAL CHIP 100K 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-833-11 METAL CHIP 10K 5% 1/16W
R305 1-216-864-11 METAL CHIP 0 5% 1/16W
R307 1-216-864-11 METAL CHIP 0 5% 1/16W
R320 1-216-864-11 METAL CHIP 0 5% 1/16W
R321 1-216-864-11 METAL CHIP 0 5% 1/16W
R322 1-216-864-11 METAL CHIP 0 5% 1/16W
R323 1-216-864-11 METAL CHIP 0 5% 1/16W
R324 1-216-864-11 METAL CHIP 0 5% 1/16W
R325 1-216-864-11 METAL CHIP 0 5% 1/16W
R350 1-216-821-11 METAL CHIP 1K 5% 1/16W
R351 1-216-821-11 METAL CHIP 1K 5% 1/16W
R353 1-216-833-11 METAL CHIP 10K 5% 1/16W
R354 1-216-833-11 METAL CHIP 10K 5% 1/16W
R356 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R369 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R370 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R502 1-216-809-11 METAL CHIP 100 5% 1/16W
R503 1-216-809-11 METAL CHIP 100 5% 1/16W
R504 1-216-864-11 METAL CHIP 0 5% 1/16W
R505 1-216-841-11 METAL CHIP 47K 5% 1/16W
R506 1-216-864-11 METAL CHIP 0 5% 1/16W
R507 1-216-864-11 METAL CHIP 0 5% 1/16W
R508 1-216-864-11 METAL CHIP 0 5% 1/16W
R509 1-216-833-11 METAL CHIP 10K 5% 1/16W
R511 1-216-864-11 METAL CHIP 0 5% 1/16W
R513 1-216-864-11 METAL CHIP 0 5% 1/16W
R515 1-216-864-11 METAL CHIP 0 5% 1/16W
R516 1-216-864-11 METAL CHIP 0 5% 1/16W
R517 1-216-864-11 METAL CHIP 0 5% 1/16W
R518 1-216-864-11 METAL CHIP 0 5% 1/16W
R519 1-216-864-11 METAL CHIP 0 5% 1/16W
R520 1-216-833-11 METAL CHIP 10K 5% 1/16W
R522 1-216-845-11 METAL CHIP 100K 5% 1/16W
R523 1-216-864-11 METAL CHIP 0 5% 1/16W
R524 1-216-845-11 METAL CHIP 100K 5% 1/16W
R526 1-216-864-11 METAL CHIP 0 5% 1/16W
R527 1-216-864-11 METAL CHIP 0 5% 1/16W
R528 1-216-864-11 METAL CHIP 0 5% 1/16W
R529 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R530 1-216-864-11 METAL CHIP 0 5% 1/16W
R532 1-216-864-11 METAL CHIP 0 5% 1/16W
CDR

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
