Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
95
RCD-W10
R533 1-216-864-11 METAL CHIP 0 5% 1/16W
R534 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R535 1-216-864-11 METAL CHIP 0 5% 1/16W
R536 1-216-864-11 METAL CHIP 0 5% 1/16W
R537 1-216-864-11 METAL CHIP 0 5% 1/16W
R538 1-216-864-11 METAL CHIP 0 5% 1/16W
R539 1-216-864-11 METAL CHIP 0 5% 1/16W
R540 1-216-833-11 METAL CHIP 10K 5% 1/16W
R542 1-216-833-11 METAL CHIP 10K 5% 1/16W
R543 1-216-833-11 METAL CHIP 10K 5% 1/16W
R544 1-216-864-11 METAL CHIP 0 5% 1/16W
R545 1-216-864-11 METAL CHIP 0 5% 1/16W
R546 1-216-864-11 METAL CHIP 0 5% 1/16W
R547 1-216-864-11 METAL CHIP 0 5% 1/16W
R548 1-216-864-11 METAL CHIP 0 5% 1/16W
R549 1-216-864-11 METAL CHIP 0 5% 1/16W
R550 1-216-864-11 METAL CHIP 0 5% 1/16W
R555 1-216-833-11 METAL CHIP 10K 5% 1/16W
R556 1-216-833-11 METAL CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB201 1-233-810-21 RES, NETWORK 100K (3216)
RB504 1-233-810-21 RES, NETWORK 100K (3216)
RB505 1-233-810-21 RES, NETWORK 100K (3216)
RB506 1-233-810-21 RES, NETWORK 100K (3216)
RB508 1-233-810-21 RES, NETWORK 100K (3216)
RB509 1-233-810-21 RES, NETWORK 100K (3216)
RB510 1-233-810-21 RES, NETWORK 100K (3216)
RB511 1-233-810-21 RES, NETWORK 100K (3216)
RB512 1-233-810-21 RES, NETWORK 100K (3216)
RB513 1-233-810-21 RES, NETWORK 100K (3216)
RB514 1-233-810-21 RES, NETWORK 100K (3216)
RB515 1-233-810-21 RES, NETWORK 100K (3216)
RB516 1-233-810-21 RES, NETWORK 100K (3216)
RB517 1-233-810-21 RES, NETWORK 100K (3216)
RB518 1-233-810-21 RES, NETWORK 100K (3216)
RB519 1-233-810-21 RES, NETWORK 100K (3216)
RB520 1-233-810-21 RES, NETWORK 100K (3216)
RB521 1-233-810-21 RES, NETWORK 100K (3216)
RB522 1-233-810-21 RES, NETWORK 100K (3216)
< SWITCH >
S170 1-786-288-11 SWITCH, DETECTION (LOAD IN SW)
S171 1-786-288-11 SWITCH, DETECTION (LOAD OUT SW)
< VIBRATOR >
X201 1-795-519-11 VIBRATOR, CRYSTAL 33.8688MHz
X501 1-795-622-21 VIBRATOR, CERAMIC 20MHz
************************************************************
1-683-867-11 CD-SW BOARD
************
< CAPACITOR >
C720 1-164-159-11 CERAMIC 0.1uF 50V
< RESISTOR >
R725 1-249-417-11 CARBON 1K 5% 1/4W F
R726 1-249-419-11 CARBON 1.5K 5% 1/4W F
R727 1-249-421-11 CARBON 2.2K 5% 1/4W F
R728 1-249-425-11 CARBON 4.7K 5% 1/4W F
R729 1-249-429-11 CARBON 10K 5% 1/4W
< SWITCH >
S725 1-762-875-21 SWITCH, KEYBOARD (PLAY MODE)
S726 1-762-875-21 SWITCH, KEYBOARD (TIME)
S727 1-762-875-21 SWITCH, KEYBOARD (H)
S728 1-762-875-21 SWITCH, KEYBOARD (X)
S729 1-762-875-21 SWITCH, KEYBOARD (x)
************************************************************
A-4728-267-A DISPLAY BOARD, COMPLETE
************************
4-949-935-41 CUSHION (FL)
* 4-996-686-03 HOLDER (FL)
< CAPACITOR >
C742 1-124-584-00 ELECT 100uF 20% 10V
C743 1-164-159-11 CERAMIC 0.1uF 50V
C750 1-164-159-11 CERAMIC 0.1uF 50V
C751 1-124-261-00 ELECT 10uF 20% 50V
C753 1-124-261-00 ELECT 10uF 20% 50V
C760 1-124-261-00 ELECT 10uF 20% 50V
C761 1-162-294-31 CERAMIC 0.001uF 10% 50V
C762 1-162-294-31 CERAMIC 0.001uF 10% 50V
C763 1-164-159-11 CERAMIC 0.1uF 50V
C764 1-124-261-00 ELECT 10uF 20% 50V
C765 1-164-159-11 CERAMIC 0.1uF 50V
C766 1-162-215-31 CERAMIC 47PF 5% 50V
C767 1-164-159-11 CERAMIC 0.1uF 50V
C768 1-162-294-31 CERAMIC 0.001uF 10% 50V
C769 1-162-294-31 CERAMIC 0.001uF 10% 50V
C770 1-162-294-31 CERAMIC 0.001uF 10% 50V
C780 1-164-159-11 CERAMIC 0.1uF 50V
< CONNECTOR >
CN700 1-779-558-21 CONNECTOR,FFC(LIF(NON-ZIF))21P
CN710 1-750-194-11 CONNECTOR, BOARD TO BOARD 4P
< DIODE >
D775 8-719-046-39 DIODE SEL5821A-TP15 (SBM)
< FILTER >
FL750 1-518-789-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC760 8-759-680-17 IC MSM9201-04GS-K
IC781 8-759-827-69 IC NJL63H400A-1 (g)
< TRANSISTOR >
Q761 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q762 8-729-620-05 TRANSISTOR 2SC2603TP-EF
Q775 8-729-900-80 TRANSISTOR UN4211-TA
CDR CD-SW DISPLAY

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
