Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
97
RCD-W10
C211 1-136-356-11 MYLAR 470PF 5.00% 50V
C212 1-128-551-11 ELECT 22uF 20.00% 25V
C213 1-128-551-11 ELECT 22uF 20.00% 25V
C218 1-128-551-11 ELECT 22uF 20.00% 25V
C270 1-128-551-11 ELECT 22uF 20.00% 25V
C276 1-128-551-11 ELECT 22uF 20.00% 25V
C277 1-136-356-11 MYLAR 470PF 5.00% 50V
C311 1-126-933-11 ELECT 100uF 20.00% 16V
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C316 1-126-933-11 ELECT 100uF 20.00% 16V
C317 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C361 1-126-933-11 ELECT 100uF 20.00% 16V
C362 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C366 1-126-933-11 ELECT 100uF 20.00% 16V
C367 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C391 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C396 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C401 1-126-767-11 ELECT 1000uF 20.00% 16V
C403 1-126-767-11 ELECT 1000uF 20.00% 16V
C410 1-126-939-11 ELECT 10000uF 20.00% 16V
C411 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C413 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C414 1-126-926-11 ELECT 1000uF 20.00% 10V
C420 1-126-939-11 ELECT 10000uF 20.00% 16V
C421 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C423 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C424 1-126-926-11 ELECT 1000uF 20.00% 10V
C431 1-128-548-11 ELECT 4700uF 20.00% 25V
C432 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C433 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C434 1-126-926-11 ELECT 1000uF 20.00% 10V
C442 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C443 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C444 1-126-926-11 ELECT 1000uF 20.00% 10V
C451 1-128-548-11 ELECT 4700uF 20.00% 25V
C452 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C453 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C454 1-126-926-11 ELECT 1000uF 20.00% 10V
C460 1-128-576-11 ELECT 100uF 20.00% 63V
C463 1-165-319-11 CERAMIC CHIP 0.1uF 50V
C465 1-126-967-11 ELECT 47uF 20.00% 50V
C471 1-104-663-11 ELECT 33uF 20.00% 25V
C472 1-128-551-11 ELECT 22uF 20.00% 25V
C476 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C480 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C481 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C505 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C517 1-126-933-11 ELECT 100uF 20.00% 16V
C518 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C530 1-126-933-11 ELECT 100uF 20.00% 16V
C531 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C534 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C535 1-126-933-11 ELECT 100uF 20.00% 16V
C539 1-126-933-11 ELECT 100uF 20.00% 16V
C541 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C600 1-126-963-11 ELECT 4.7uF 20.00% 50V
C611 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C621 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C630 1-216-864-11 METAL CHIP 0 5% 1/16W
C670 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C802 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C805 1-126-933-11 ELECT 100uF 20.00% 16V
0 C900 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
0 C901 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
< CONNECTOR >
CN1 1-784-367-11 CONNECTOR, FFC/FPC 8P
CN630 1-784-370-21 CONNECTOR, FFC/FPC 11P
CN660 1-793-991-11 CONNECTOR, FFC/FPC 23P
CN671 1-778-692-11 CONNECTOR, FFC/FPC 21P
* CN680 1-568-954-11 PIN, CONNECTOR 5P
CN690 1-506-468-11 PIN, CONNECTOR 3P
0 CN900 1-564-321-00 PIN, CONNECTOR 2P
< DIODE >
D181 8-719-820-05 DIODE 1SS181-TE85L
D310 8-719-988-61 DIODE 1SS355TE-17
D311 8-719-801-78 DIODE 1SS184-TE85L
D316 8-719-820-05 DIODE 1SS181-TE85L
D401 8-719-200-02 DIODE 11E2-TB2
D402 8-719-200-02 DIODE 11E2-TB2
D403 8-719-200-02 DIODE 11E2-TB2
D404 8-719-200-02 DIODE 11E2-TB2
D411 8-719-200-02 DIODE 11E2-TB2
D412 8-719-200-02 DIODE 11E2-TB2
D421 8-719-200-02 DIODE 11E2-TB2
D422 8-719-200-02 DIODE 11E2-TB2
D426 1-216-295-91 SHORT CHIP 0
D431 8-719-200-02 DIODE 11E2-TB2
D432 8-719-200-02 DIODE 11E2-TB2
D433 8-719-200-02 DIODE 11E2-TB2
D434 8-719-200-02 DIODE 11E2-TB2
D451 8-719-200-02 DIODE 11E2-TB2
D452 8-719-200-02 DIODE 11E2-TB2
D453 8-719-200-02 DIODE 11E2-TB2
D454 8-719-200-02 DIODE 11E2-TB2
D461 8-719-200-02 DIODE 11E2-TB2
D462 8-719-422-64 DIODE MA8062-M-TX
D471 8-719-988-61 DIODE 1SS355TE-17
D472 8-719-988-61 DIODE 1SS355TE-17
D473 8-719-988-61 DIODE 1SS355TE-17
D805 8-719-421-82 DIODE MA8043-M(TX)
< IC >
IC1 6-802-233-01 IC uPD70F3033AYGF-M02-3BA
IC100 8-759-643-31 IC BR24C02FV-WE2
IC310 8-759-278-58 IC NJM4558V-TE2
IC370 8-759-278-58 IC NJM4558V-TE2
IC390 8-759-697-21 IC NJM4565V(TE2)
IC410 8-759-231-53 IC AN7805
IC420 8-759-231-53 IC AN7805
IC430 8-759-400-66 IC AN7808
MAIN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
