Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
98
RCD-W10
IC440 8-759-605-00 IC AN7807
IC450 8-759-400-66 IC AN7808
IC460 8-759-633-42 IC M5293L
IC476 8-759-387-77 IC TC7WU04F-TE12L
IC480 8-759-598-06 IC S-80942ANMP-DD6-T2
IC500 6-701-843-01 IC CXD9692R
IC610 6-600-013-01 IC TORX179L
IC620 6-600-011-01 IC TOTX179L
IC800 8-759-633-65 IC M54641L
< JACK >
J310 1-784-429-11 JACK, PIN 4P (ANALOG IN L/R OUT L/R )
< COIL >
L390 1-216-295-91 SHORT CHIP 0
L391 1-216-295-91 SHORT CHIP 0
L539 1-216-296-11 SHORT CHIP 0
L600 1-414-267-21 INDUCTOR 10uH
L636 1-216-295-91 SHORT CHIP 0
L665 1-216-295-91 SHORT CHIP 0
L667 1-469-670-21 FERRITE 0uH
< LINE FILTER >
0 LF900 1-419-625-11 COIL, LINE FILTER
< TRANSISTOR >
Q181 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q191 8-729-424-67 TRANSISTOR UN2216-TX
Q281 8-729-046-97 TRANSISTOR 2SD1938(F)-T(TX).SO
Q291 8-729-424-67 TRANSISTOR UN2216-TX
Q310 8-729-922-37 TRANSISTOR 2SD2144S-TP-UVW
Q380 8-729-015-74 TRANSISTOR UN5111-TX
< RESISTOR >
R3 1-216-833-11 METAL CHIP 10K 5% 1/16W
R6 1-216-833-11 METAL CHIP 10K 5% 1/16W
R12 1-216-845-11 METAL CHIP 100K 5% 1/16W
R15 1-216-833-11 METAL CHIP 10K 5% 1/16W
R18 1-216-833-11 METAL CHIP 10K 5% 1/16W
R19 1-216-849-11 METAL CHIP 220K 5% 1/16W
R20 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R21 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R25 1-216-845-11 METAL CHIP 100K 5% 1/16W
R63 1-216-833-11 METAL CHIP 10K 5% 1/16W
R64 1-216-833-11 METAL CHIP 10K 5% 1/16W
R66 1-216-845-11 METAL CHIP 100K 5% 1/16W
R72 1-216-833-11 METAL CHIP 10K 5% 1/16W
R73 1-216-833-11 METAL CHIP 10K 5% 1/16W
R87 1-216-864-11 METAL CHIP 0 5% 1/16W
R88 1-216-864-11 METAL CHIP 0 5% 1/16W
R90 1-216-833-11 METAL CHIP 10K 5% 1/16W
R94 1-216-833-11 METAL CHIP 10K 5% 1/16W
R95 1-216-833-11 METAL CHIP 10K 5% 1/16W
R107 1-216-833-11 METAL CHIP 10K 5% 1/16W
R111 1-216-839-11 METAL CHIP 33K 5% 1/16W
R112 1-216-837-11 METAL CHIP 22K 5% 1/16W
R113 1-216-849-11 METAL CHIP 220K 5% 1/16W
R115 1-216-805-11 METAL CHIP 47 5% 1/16W
R170 1-216-845-11 METAL CHIP 100K 5% 1/16W
R171 1-216-833-11 METAL CHIP 10K 5% 1/16W
R172 1-216-833-11 METAL CHIP 10K 5% 1/16W
R176 1-216-819-11 METAL CHIP 680 5% 1/16W
R177 1-216-845-11 METAL CHIP 100K 5% 1/16W
R178 1-216-815-11 METAL CHIP 330 5% 1/16W
R181 1-216-833-11 METAL CHIP 10K 5% 1/16W
R191 1-216-805-11 METAL CHIP 47 5% 1/16W
R192 1-216-805-11 METAL CHIP 47 5% 1/16W
R193 1-216-864-11 METAL CHIP 0 5% 1/16W
R211 1-216-839-11 METAL CHIP 33K 5% 1/16W
R212 1-216-837-11 METAL CHIP 22K 5% 1/16W
R213 1-216-849-11 METAL CHIP 220K 5% 1/16W
R215 1-216-805-11 METAL CHIP 47 5% 1/16W
R270 1-216-845-11 METAL CHIP 100K 5% 1/16W
R271 1-216-833-11 METAL CHIP 10K 5% 1/16W
R272 1-216-833-11 METAL CHIP 10K 5% 1/16W
R276 1-216-819-11 METAL CHIP 680 5% 1/16W
R277 1-216-845-11 METAL CHIP 100K 5% 1/16W
R278 1-216-815-11 METAL CHIP 330 5% 1/16W
R281 1-216-833-11 METAL CHIP 10K 5% 1/16W
R291 1-216-805-11 METAL CHIP 47 5% 1/16W
R292 1-216-805-11 METAL CHIP 47 5% 1/16W
R293 1-216-864-11 METAL CHIP 0 5% 1/16W
R310 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R311 1-216-841-11 METAL CHIP 47K 5% 1/16W
R380 1-216-845-11 METAL CHIP 100K 5% 1/16W
R381 1-216-847-11 METAL CHIP 150K 5% 1/16W
R461 1-216-837-11 METAL CHIP 22K 5% 1/16W
R462 1-216-845-11 METAL CHIP 100K 5% 1/16W
R463 1-216-813-11 METAL CHIP 220 5% 1/16W
R464 1-216-813-11 METAL CHIP 220 5% 1/16W
R471 1-216-809-11 METAL CHIP 100 5% 1/16W
R472 1-216-817-11 METAL CHIP 470 5% 1/16W
R473 1-216-817-11 METAL CHIP 470 5% 1/16W
R474 1-216-837-11 METAL CHIP 22K 5% 1/16W
R475 1-216-842-11 METAL CHIP 56K 5% 1/16W
R476 1-216-851-11 METAL CHIP 330K 5% 1/16W
R477 1-216-821-11 METAL CHIP 1K 5% 1/16W
R480 1-216-841-11 METAL CHIP 47K 5% 1/16W
R500 1-216-864-11 METAL CHIP 0 5% 1/16W
R504 1-216-864-11 METAL CHIP 0 5% 1/16W
R506 1-216-809-11 METAL CHIP 100 5% 1/16W
R507 1-216-809-11 METAL CHIP 100 5% 1/16W
R508 1-216-809-11 METAL CHIP 100 5% 1/16W
R509 1-216-809-11 METAL CHIP 100 5% 1/16W
R510 1-216-809-11 METAL CHIP 100 5% 1/16W
R511 1-216-809-11 METAL CHIP 100 5% 1/16W
R513 1-216-809-11 METAL CHIP 0 5% 1/10W
R514 1-216-864-11 METAL CHIP 0 5% 1/16W
R516 1-216-864-11 METAL CHIP 0 5% 1/16W
R526 1-216-833-11 METAL CHIP 10K 5% 1/16W
R540 1-216-834-11 METAL CHIP 12K 5% 1/16W
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
