Sony RCD-W10 Service Manual

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
99
RCD-W10
R544 1-216-864-11 METAL CHIP 0 5% 1/16W
R550 1-216-864-11 METAL CHIP 0 5% 1/16W
R611 1-216-817-11 METAL CHIP 470 5% 1/16W
R636 1-216-864-11 METAL CHIP 0 5% 1/16W
R665 1-216-864-11 METAL CHIP 0 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB43 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB47 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB51 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB54 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB68 1-236-908-11 RES, CHIP NETWORK 10K (3216)
RB77 1-233-418-11 RES, CHIP NETWORK 3.3K (3216)
< RELAY >
RY310 1-515-622-11 RELAY
< VIBRATOR >
X38 1-795-721-21 VIBRATOR, CERAMIC 20MHz
************************************************************
1-683-869-11 POWER-SW BOARD
****************
< CAPACITOR >
0 C921 1-113-920-11 CERAMIC 0.0022uF 20.00% 250V
< CONNECTOR >
0* CN920 1-580-230-31 PIN, CONNECTOR (PC BOARD) 2P
< SWITCH >
0 S921 1-572-267-51 SWITCH, PUSH (AC POWER)(1 KEY) (POWER)
************************************************************
MISCELLANEOUS
**************
0 6 1-783-531-32 CORD, POWER (CND)
0 6 1-783-531-42 CORD, POWER (US)
63 1-823-923-11 WIRE (FLAT TYPE) (21 CORE)
106 1-823-926-11 WIRE (FLAT TYPE) (23 CORE)
108 1-823-922-11 WIRE (FLAT TYPE) (11 CORE)
501 1-823-651-11 CABLE, FLEXIBLE FLAT (32 CORE)
0 503 8-583-104-01 OPTICAL PICK-UP (KRM-220CAA)
* 509 1-452-958-11 MAGNET (CHUCKING)
602 1-782-817-11 WIRE (FLAT TYPE) (16 CORE)
0 607 A-4735-189-A OP ASSY (A-MAX.3)
M201 A-4735-557-A MOTOR ASSY (LOADING)
M151 1-763-790-11 MOTOR, DC (LOADING)
0 T900 1-437-623-11 TRANSFORMER, POWER
************************************************************
ACCESSORIES
************
1-477-038-11 REMOTE COMMANDER (RM-R51)
1-558-271-11 CORD, CONNECTION
1-776-263-51 CORD, CONNECTION
4-242-051-11 MANUAL, INSTRUCTION (ENGLISH)
4-242-051-21 MANUAL, INSTRUCTION (FRENCH)
4-981-643-01 COVER, BATTERY (FOR RM-R51)
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
pièce portant le numéro spécifié.
MAIN POWER-SW

Sony RCD-W10 Specifications

Power

North American model power requirements	120 V AC, 60 Hz
Mexican model power requirements	120 V AC, 60 Hz
Other models power requirements	110-120/220-240V AC, 50/60 Hz
Power consumption	25 W

Inputs

ANALOG IN impedance	47 kilohms
ANALOG IN rated input	500 mVrms
ANALOG IN minimum input	250 mVrms

Outputs

ANALOG OUT impedance	47 kilohms
ANALOG OUT rated output	2 Vrms
ANALOG OUT load impedance	over 10 kilohms

Weight and Dimensions

dimensions	430 × 108 × 399 mm
RCD-W50C mass	6.8 kg
RCD-W10 mass	6.0 kg
