COLOR MISSING IN
RECORD MODE
(VIDEO IN)
RECORD MODE
(VCR Section)
NOTE: XT301 - Always (3.579545MHz)
COLOR signal
IC301-46
COLOR KILLER
IC301 "60"(2V)
CHANGE
IC301
CHECK THE REC LINE
SEE PAGE 7-9
(VIDEO MISSING IN RECORD
MODE)
NO
NO
NO
YES
NO
YES
CHECK XT301
CHANGE XT301
NO
NO
CHANGE IC301
