8-7
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
VCR MAIN
LD703 9-885-076-82 LED (PROGRESSIVE)
LD704 9-885-076-83 LED (SYNCRO REC)
< MODULE >
RM701 9-885-069-95 MODULE REMOCON TSOP2240RF1
< SWITCH >
SW703 9-885-069-77 SWITCH-TACT (PAUSE)
SW705 9-885-069-77 SWITCH-TACT (VIDEO)
SW706 9-885-069-77 SWITCH-TACT (COPYD2V)
SW707 9-885-069-77 SWITCH-TACT (PLAY)
SW708 9-885-069-77 SWITCH-TACT (DVD)
SW709 9-885-069-77 SWITCH-TACT (EJECT)
SW710 9-885-069-77 SWITCH-TACT (COPYV2D)
SW711 9-885-069-77 SWITCH-TACT (REC)
SW713 9-885-069-77 SWITCH-TACT (FF)
SW714 9-885-069-77 SWITCH-TACT (OPEN)
SW715 9-885-069-77 SWITCH-TACT (REW)
SW716 9-885-069-77 SWITCH-TACT (STOP)
VCR MAIN BOARD
***************
SC1S01 9-885-069-86 SCREW-TAPTITE ZPC (YEL) SWRC
SC1S33 9-885-069-86 SCREW-TAPTITE ZPC (YEL) SWRC
< CAPACITOR >
C319 1-100-020-11 CONDENSER 10000PF
C502 1-165-563-11 CONDENSER 0.1uF
C522 1-100-020-11 CONDENSER 10000PF
C635 1-100-020-11 CONDENSER 10000PF
C636 1-100-020-11 CONDENSER 10000PF
0 C1S02 1-100-358-11 CONDENSER CERAMIC DISC 100PF
0 C1S03 1-100-358-11 CONDENSER CERAMIC DISC 100PF
0 C1S04 9-885-081-57 CONDENSER FILM 47000PF
0 C1S05 9-885-081-57 CONDENSER FILM 47000PF
0 C1S06 9-885-060-93 CONDENSER 2.2nF
C1S07 1-165-990-11 CONDENSER 100PF
C1S08 1-165-574-11 CONDENSER FILM 10000PF
C1S12 1-165-574-11 CONDENSER FILM 10000PF
C1S39 1-165-999-11 CONDENSER FILM 0.1uF
< CONNECTOR >
CN02 1-815-688-11 CONNECTOR FPC 6PSN
CN301 1-815-685-11 CONNECTOR FPC 10P
CN303 1-815-688-11 CONNECTOR FPC 6PSN
< FLAT CABLE >
CN01B 9-885-095-60 CABLE-FLAT 27PIN
CN303B 9-885-069-80 CABLE-FLAT
* CNJ01B 9-885-102-65 CABLE-FLAT 6P
* CNJ02B 9-885-102-66 CABLE-FLAT 14P
< DIODE >
* BD01 9-885-103-76 DIODE SHL20K
* BD02 9-885-103-76 DIODE SHL20K
* BD03 9-885-103-76 DIODE SHL20K
* BD04 9-885-103-76 DIODE SHL20K
D601 9-885-070-12 DIODE 1N4148
* D604 9-885-103-77 DIODE 1N5819 (Mexican)
D605 9-885-070-12 DIODE 1N4148
* D606 9-885-103-77 DIODE 1N5819 (Mexican)
D1P102 9-885-070-12 DIODE 1N4148
D1P103 1-804-409-11 DIODE 1N4002
D1P104 1-804-409-11 DIODE 1N4002
* D1P106 9-885-103-77 DIODE 1N5819 (Mexican)
* D1P107 9-885-103-77 DIODE 1N5819 (Mexican)
D1S05 9-885-070-13 DIODE UF4007
D1S06 9-885-070-12 DIODE 1N4148
D1S07 9-885-070-16 DIODE F1T4
D1S30 9-885-076-80 DIODE MBRF10A0
D1S32 9-885-076-80 DIODE MBRF10A0
D1S33 9-885-076-80 DIODE MBRF10A0
D1S34 9-885-070-16 DIODE F1T4
D1S35 9-885-070-15 DIODE SHG2D
D1S36 9-885-070-16 DIODE F1T4
D1S37 9-885-070-16 DIODE F1T4
* D1S38 9-885-102-60 DIODE 1N5408
D1S40 9-885-070-16 DIODE F1T4
ZD401 9-885-070-19 DIODE UZP33B
ZD1P03 9-885-070-21 DIODE MTZJ9
ZD1P05 9-885-070-18 DIODE UZP27B
ZD1P06 9-885-070-17 DIODE UZ5.6BM
ZD1S01 9-885-070-25 DIODE MTZJ4
ZD1S02 9-885-036-94 DIODE MTZJ20B
ZD1S03 1-804-803-11 DIODE MTZ6.2B
< FUSE >
0 F1P01 1-576-729-11 FUSE-RADIAL LEAD (1A/50V)
0 F1S01 9-885-069-78 FUSE-CARTRIDGE (1.6A/250V)
< FUSE CLIP >
FC1S01 1-576-527-11 FUSE CLIP
FC1S02 1-576-527-11 FUSE CLIP
< IC >
IC301 9-885-070-58 IC LA71207 (VIDEO PROCESS)
IC501 9-885-070-60 IC LA72670M (SIGNAL PROCESSOR)
IC601 9-885-105-22 IC MN101D10G-CH (MICOM)
IC603 9-885-079-45 IC S524A (EEPROM)
IC1P01 9-885-070-56 IC G9105 (POSI. FIXED REG)
IC1P02 9-885-084-28 IC (SWITCH VOL. REG)
IC1P03 9-885-070-56 IC G9105 (POSI. FIXED REG)
IC1P04 9-885-102-61 IC KIA278R018PI (POSI. FIXED REG)
IC1P05 9-885-070-57 IC G9205 (POSI. FIXED REG)
IC1S01 9-885-037-01 IC (PWM CONTROLLER)
0 IC1S02 9-885-070-43 PHOTO-COUPLER
IC1S03 1-804-445-11 IC KA4318
IC6B1 1-804-773-11 IC (RESET)
< COIL/FERRITE BEAD >
BD1P01 1-400-086-11 FERRITE CORE
BD1S01 1-400-085-11 INDUCTOR 70uH
BD1S02 1-400-085-11 INDUCTOR 70uH
L02 1-424-828-11 COIL CHOKE 10uH
L03 1-424-828-11 COIL CHOKE 10uH
L301 1-400-085-11 INDUCTOR 70uH
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
