Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
L302 1-400-086-11 FERRITE CORE
L303 1-400-086-11 FERRITE CORE
L304 1-400-086-11 FERRITE CORE
L305 1-400-085-11 INDUCTOR 70uH
L306 9-885-070-66 INDUCTOR-RADIAL
L307 1-400-074-11 INDUCTOR 100uH
L501 1-400-086-11 FERRITE CORE
L502 1-400-086-11 FERRITE CORE
L601 1-400-082-11 INDUCTOR RA 100uH
L602 1-400-074-11 INDUCTOR 100uH
L603 1-400-074-11 INDUCTOR 100uH
L1P101 1-400-074-11 INDUCTOR 100uH
L1S30 9-885-070-00 COIL CHOKE DR CHOKE (8*6)
L1S31 9-885-070-00 COIL CHOKE DR CHOKE (8*6)
L1S32 1-424-828-11 COIL CHOKE 10uH
< LINE FILTER >
0 L1S01 1-424-831-11 LINE FILTER 20mH
0 L1S02 1-424-830-11 LINE FILTER 30mH
< LED >
LD601 9-885-060-84 LED-IR (T/S LED)
< TRANSFORMER >
0 PT01 9-885-102-62 TRANS SWITCHING;EER3534
< PHOTO INTERRUPTER >
PT601 9-885-060-86 PHOTO INTERRUPTER (S-REEL)
PT602 9-885-060-86 PHOTO INTERRUPTER (T-REEL)
< TRANSISTOR >
Q302 9-885-060-82 TRANSISTOR KSA812
Q303 9-885-070-30 TRANSISTOR KSC1623-L
Q304 9-885-060-82 TRANSISTOR KSA812
Q305 9-885-070-33 TRANSISTOR KTC3203-Y
Q306 9-885-060-82 TRANSISTOR KSA812
Q307 9-885-070-33 TRANSISTOR KTC3203-Y
Q308 9-885-070-33 TRANSISTOR KTC3203-Y
Q601 9-885-043-26 TRANSISTOR KSR1104
Q1P103 9-885-070-38 FET FQP33N10
Q1P108 9-885-060-83 TRANSISTOR KSC2328AY
Q1PS01 9-885-070-32 TRANSISTOR KSC945
Q1PS02 9-885-070-33 TRANSISTOR KTC3203-Y
Q1PS03 9-885-070-36 TRANSISTOR KSR2001
Q1S01 9-885-036-95 FET
< RESISTOR >
R1S13 1-245-575-11 R-METAL OXIDE
< THERMISTOR >
0 R1S04 9-885-101-36 THERMISTOR-NTC
< PHOTO TRANSISTOR >
S601 9-885-060-85 PHOTO TRANSISTOR (END SENSOR)
S602 9-885-060-85 PHOTO TRANSISTOR (START SENSOR)
< SWITCH >
SW602 9-885-101-37 SWITCH REC (REC-SW)
SW603 9-885-061-06 SWITCH MODE (MODE-SW)
< VARISTOR >
VA1S01 9-885-070-65 VARISTOR
VA1S02 9-885-070-65 VARISTOR
< VIBRATOR >
XT301 1-795-603-11 VIBRATOR CRYSTAL (3.579545MHz)
XT601 9-885-070-67 CRYSTAL-UNIT (14.31818MHz)
XT602 1-795-332-11 VIBRATOR CRYSTAL (32.768kHz) (Mexican)
MISCELLANEOUS
***************
6 9-885-090-91 FAN-DC
9 9-885-102-43 CABLE-FLAT;30V, 80C, 360MM, 40P
0 P025 1-824-674-11 POWER CORD EP2 SPT-2 (US, Canadian)
0 P025 9-885-083-78 CBF-POWER CORD (Mexican)
ACCESSORIES
************
2-672-429-11 MANUAL, INSTRUCTION (ENGLISH)
(VX530: US, Canadian)
2-672-429-21 MANUAL, INSTRUCTION (FRENCH)
(VX530: Canadian)
2-672-430-11 MANUAL, INSTRUCTION (ENGLISH) (VX521)
2-672-431-11 MANUAL, INSTRUCTION (SPANISH)
(VX530: Mexican)
9-885-102-44 CBF CABLE-MONO PLUG TO LED
(US, Canadian)
VCR MAIN
8-8E
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
