2-2
2-3. FRONT PANEL-2
2-4. AI-20, MB-94 BOARDS
qh Three screws
(+BVTP
2.6
×
8
)
qk Flap guide (L) assy
w; SP spring
qj SP spring
ql Two screws (+BVTP
2.6
×
8
)
wa Flap
frame assy
DVP-CX860 model
qa Two screws (+BVTP
2.6
×
8
)
7 Three screws
(+BVTP
2.6
×
8
)
4 Three screws
(+BVTP
2.6
×
8
)
qs Flat cable (CN102, 23p)
qd Flat cable (CN101, 15p)
3 Flat cable (CN405, 3p)
5 Flat cable
(CN403, 15p)
6 FL-115 board
q; Rotary encoder
9 Cursor stick
8 Shuttle ring
1 ACS/AMS knob
qg FR-173
board
2 Rotary encoder
(CN404, 9p)
DVP-CX870D
model
ws Door
block assy
ws Door
block assy
qf Door block assy
(CN103, 2p)
q; Four screws
(+BV 3 ×
6
)
3 Four screws
(+BV 3 ×
6
)
1 Flat cable
(CN801, 18p)
8 Flat cable
(CN104, 15p)
2 Flat cable (CN802, 15p)
2 Flat cable (CN307, 16p)
7 Flat cable
(CN301, 18p)
4 Board to board connector
(CN502, 18p)
5 Board to board connector
(CN702, 18p)
qs AI Bracket assy
qa AI-20 board
6 MB-94 board
To Next Page
