Sony RMT-D123A - Internal Views

2-6
2-11.INTERNAL VIEWS
FRONT PANEL SIDE
Base Unit
Turn Table
Door Open/Close Motor
Turn Table Motor
Table Sensor
Chuck Frame Block
Laser Diode
Sled Motor
Spindle Motor
• BASE UNIT SECTION
