Sony RMT-D123A - Turn Table Assembly; Base Unit Section

2-4
2-7. TURN TABLE ASSEMBLY
2-8. BASE UNIT SECTION
7 Four screws
(+BV
3 × 6 )
8 Screw
(+BV
3 × 6 )
qh Turn table assy
qg Two screws
(+BV
3 × 10 )
qj
9
q;
Five screws (+BV 3 × 10 )
5 Three screws (+BV 3 × 10 )
3 Screw (+BV 3 × 10 )
4 Chuck driving link
A
A
D
B
B
C
D
C
6
Center guide assy
qf CK-97 board
qd Board to board connector (CN002, 6p)
qs Board to board
connector (CN001, 4p)
1 Flat cable (CN003, 20p)
2 Flat cable
(CN004, 16p)
qa Flat cable
(CN003, 11p)
ql Mechanical
chassis section
qk Base
unit section
5 Three step screws
9 Two screws
(+BVTP 2.6 × 8)
q; TK-59 board
1 Slider (U)
2 Slider (B)
qa BU holder
8 Optical device
4 Optical device (CN001, 23p)
3 Optical device (CN002, 13p)
6 Two insulators
7 Insulator
