Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-ST9
84
< IC >
IC7001 6-721-694-01 IC RT7272BGSP
IC7002 6-716-993-01 IC MM1836A33NRE
IC7003 6-721-874-01 IC RT7295CGJ6F
IC7004 6-721-021-01 IC TAS5624ADDVR (See Note)
IC7005 6-721-021-01 IC TAS5624ADDVR (See Note)
IC7006 6-718-103-01 IC TAS5538DGGR
IC7007 6-721-021-01 IC TAS5624ADDVR (See Note)
IC7008 6-721-021-01 IC TAS5624ADDVR (See Note)
< JUMPER RESISTOR >
JC7007 1-216-864-11 SHORT CHIP 0
JC7016 1-216-864-11 SHORT CHIP 0
< COIL >
L7001 1-457-850-11 CHOKE COIL 22uH
* L7002 1-460-599-11 COIL, CHOKE 4.7uH
L7003 1-400-789-21 INDUCTOR 2.2uH
L7004 1-400-789-21 INDUCTOR 2.2uH
L7005 1-469-555-21 INDUCTOR 10uH
L7006 1-460-758-11 COIL, CHOKE 8.2uH
L7007 1-460-758-11 COIL, CHOKE 8.2uH
L7008 1-460-758-11 COIL, CHOKE 8.2uH
L7009 1-460-758-11 COIL, CHOKE 8.2uH
L7010 1-469-555-21 INDUCTOR 10uH
L7011 1-460-758-11 COIL, CHOKE 8.2uH
L7012 1-460-758-11 COIL, CHOKE 8.2uH
L7013 1-469-555-21 INDUCTOR 10uH
L7014 1-460-758-11 COIL, CHOKE 8.2uH
L7015 1-469-555-21 INDUCTOR 10uH
L7016 1-460-758-11 COIL, CHOKE 8.2uH
L7017 1-469-555-21 INDUCTOR 10uH
L7018 1-460-758-11 COIL, CHOKE 8.2uH
L7019 1-460-758-11 COIL, CHOKE 8.2uH
L7020 1-460-758-11 COIL, CHOKE 8.2uH
L7021 1-460-758-11 COIL, CHOKE 8.2uH
L7022 1-469-555-21 INDUCTOR 10uH
L7023 1-460-758-11 COIL, CHOKE 8.2uH
L7024 1-460-758-11 COIL, CHOKE 8.2uH
L7025 1-460-758-11 COIL, CHOKE 8.2uH
L7026 1-460-758-11 COIL, CHOKE 8.2uH
< TRANSISTOR >
Q7001 6-552-892-01 TRANSISTOR LSCR523UBFS8TL
Q7002 8-729-013-22 TRANSISTOR HN1A01FU
Q7003 6-552-446-01 TRANSISTOR DRC5144T0L
Q7004 6-553-470-01 FET QM2401C1
Q7005 8-729-013-22 TRANSISTOR HN1A01FU
Q7006 6-552-936-01 TRANSISTOR LTC014EUBFS8TL
Q7007 8-729-013-22 TRANSISTOR HN1A01FU
Q7008 8-729-013-22 TRANSISTOR HN1A01FU
Q7009 8-729-013-22 TRANSISTOR HN1A01FU
Q7010 8-729-013-22 TRANSISTOR HN1A01FU
Q7011 8-729-013-22 TRANSISTOR HN1A01FU
Q7012 8-729-013-22 TRANSISTOR HN1A01FU
< RESISTOR >
R7001 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7003 1-218-961-11 METAL CHIP 4.7K 5% 1/16W
R7004 1-218-973-11 METAL CHIP 47K 5% 1/16W
R7005 1-218-967-11 METAL CHIP 15K 5% 1/16W
R7006 1-218-969-11 METAL CHIP 22K 5% 1/16W
R7007 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R7008 1-218-959-11 METAL CHIP 3.3K 5% 1/16W
R7009 1-218-973-11 METAL CHIP 47K 5% 1/16W
R7010 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7011 1-218-973-11 METAL CHIP 47K 5% 1/16W
R7012 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R7013 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R7016 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7017 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7018 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7019 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R7020 1-218-937-11 METAL CHIP 47 5% 1/16W
R7021 1-216-001-00 METAL CHIP 10 5% 1/10W
R7022 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7023 1-218-937-11 METAL CHIP 47 5% 1/16W
R7024 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7025 1-216-001-00 METAL CHIP 10 5% 1/10W
R7026 1-218-937-11 METAL CHIP 47 5% 1/16W
R7027 1-216-001-00 METAL CHIP 10 5% 1/10W
R7028 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7029 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7030 1-218-937-11 METAL CHIP 47 5% 1/16W
R7031 1-218-990-81 SHORT CHIP 0
R7032 1-216-001-00 METAL CHIP 10 5% 1/10W
R7033 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7034 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7036 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R7037 1-218-937-11 METAL CHIP 47 5% 1/16W
R7038 1-216-001-00 METAL CHIP 10 5% 1/10W
R7039 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7040 1-218-937-11 METAL CHIP 47 5% 1/16W
R7041 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7042 1-218-949-11 METAL CHIP 470 5% 1/16W
R7043 1-218-949-11 METAL CHIP 470 5% 1/16W
R7044 1-216-001-00 METAL CHIP 10 5% 1/10W
R7045 1-218-967-11 METAL CHIP 15K 5% 1/16W
R7046 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7047 1-218-937-11 METAL CHIP 47 5% 1/16W
R7048 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R7049 1-216-001-00 METAL CHIP 10 5% 1/10W
R7050 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7051 1-218-937-11 METAL CHIP 47 5% 1/16W
R7052 1-218-941-81 METAL CHIP 100 5% 1/16W
R7053 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7054 1-218-941-81 METAL CHIP 100 5% 1/16W
R7055 1-218-990-81 SHORT CHIP 0
R7056 1-218-941-81 METAL CHIP 100 5% 1/16W
R7057 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7058 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7059 1-216-001-00 METAL CHIP 10 5% 1/10W
R7060 1-218-941-81 METAL CHIP 100 5% 1/16W
R7061 1-218-941-81 METAL CHIP 100 5% 1/16W
R7062 1-218-937-11 METAL CHIP 47 5% 1/16W
R7063 1-218-941-81 METAL CHIP 100 5% 1/16W
R7064 1-218-965-11 METAL CHIP 10K 5% 1/16W
R7065 1-218-941-81 METAL CHIP 100 5% 1/16W
R7066 1-218-965-11 METAL CHIP 10K 5% 1/16W
Note: When IC7004, IC7005, IC7007 and IC7008 on the AMP board are replaced, refer
to “NOTE OF REPLACING THE IC7004, IC7005, IC7007 AND IC7008 ON
THE AMP BOARD AND THE COMPLETE AMP BOARD” on page 6.
AMP
To Next Page
