Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-ST9
85
R7067 1-218-937-11 METAL CHIP 47 5% 1/16W
R7068 1-218-937-11 METAL CHIP 47 5% 1/16W
R7069 1-218-937-11 METAL CHIP 47 5% 1/16W
R7070 1-218-937-11 METAL CHIP 47 5% 1/16W
R7071 1-218-937-11 METAL CHIP 47 5% 1/16W
R7072 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7073 1-218-937-11 METAL CHIP 47 5% 1/16W
R7074 1-218-937-11 METAL CHIP 47 5% 1/16W
R7075 1-218-953-11 METAL CHIP 1K 5% 1/16W
R7076 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7077 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R7078 1-218-937-11 METAL CHIP 47 5% 1/16W
R7079 1-216-001-00 METAL CHIP 10 5% 1/10W
R7080 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7081 1-218-937-11 METAL CHIP 47 5% 1/16W
R7082 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7083 1-216-001-00 METAL CHIP 10 5% 1/10W
R7084 1-218-937-11 METAL CHIP 47 5% 1/16W
R7085 1-216-001-00 METAL CHIP 10 5% 1/10W
R7086 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7087 1-218-937-11 METAL CHIP 47 5% 1/16W
R7088 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7089 1-218-990-81 SHORT CHIP 0
R7090 1-216-001-00 METAL CHIP 10 5% 1/10W
R7091 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7092 1-208-922-11 METAL CHIP 30K 0.5% 1/16W
R7093 1-218-937-11 METAL CHIP 47 5% 1/16W
R7094 1-216-001-00 METAL CHIP 10 5% 1/10W
R7095 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7096 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7097 1-218-937-11 METAL CHIP 47 5% 1/16W
R7098 1-216-001-00 METAL CHIP 10 5% 1/10W
R7099 1-218-990-81 SHORT CHIP 0
R7100 1-216-001-00 METAL CHIP 10 5% 1/10W
R7101 1-216-001-00 METAL CHIP 10 5% 1/10W
R7102 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7103 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7104 1-218-977-11 METAL CHIP 100K 5% 1/16W
R7105 1-218-937-11 METAL CHIP 47 5% 1/16W
R7106 1-218-937-11 METAL CHIP 47 5% 1/16W
R7108 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R7109 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
*************************************************************
A-2054-813-A DISPLAY BOARD, COMPLETE
***********************
< CAPACITOR >
* C1301 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1302 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C1303 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C1304 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C1305 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C1306 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
C1307 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C1308 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C1309 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
C1310 1-118-046-11 CERAMIC CHIP 4.7uF 10% 25V
* C1311 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
C1316 1-118-952-11 CERAMIC CHIP 1uF 10% 50V
< CONNECTOR >
CN1303 1-580-057-11 PIN, CONNECTOR (SMD) 4P
CN1304 1-816-649-51 FFC/CONNECTOR, FPC (LIF) 22P
CN1305 1-816-654-61 FFC/CONNECTOR, FPC (LIF) 6P
CN1306 1-816-645-61 FFC/CONNECTOR, FPC (LIF) 14P
< LED >
D1302 6-503-196-01 LED CL-194S-HB8SP-SD-T
(Bluetooth INDICATOR)
< IC >
IC1301 6-600-681-01 IC RS-770N (
)
< TRANSISTOR >
Q1302 6-552-941-01 TRANSISTOR LTC023JUBFS8TL
< RESISTOR >
R1302 1-218-937-11 METAL CHIP 47 5% 1/16W
R1303 1-218-937-11 METAL CHIP 47 5% 1/16W
R1305 1-218-937-11 METAL CHIP 47 5% 1/16W
R1306 1-218-937-11 METAL CHIP 47 5% 1/16W
R1307 1-220-216-81 METAL CHIP 620K 5% 1/16W
R1309 1-218-942-11 METAL CHIP 120 5% 1/16W
R1310 1-218-937-11 METAL CHIP 47 5% 1/16W
R1311 1-218-937-11 METAL CHIP 47 5% 1/16W
R1312 1-218-990-81 SHORT CHIP 0
R1314 1-218-941-81 METAL CHIP 100 5% 1/16W
R1315 1-218-941-81 METAL CHIP 100 5% 1/16W
R1316 1-218-941-81 METAL CHIP 100 5% 1/16W
R1317 1-218-941-81 METAL CHIP 100 5% 1/16W
R1318 1-218-941-81 METAL CHIP 100 5% 1/16W
R1319 1-218-990-81 SHORT CHIP 0
*************************************************************
IO BOARD
********
< CAPACITOR >
C1701 1-118-354-11 CERAMIC CHIP 1000PF 5% 100V
C1702 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C1703 1-164-882-11 CERAMIC CHIP 220PF 5% 16V
C1704 1-118-347-11 CERAMIC CHIP 0.1uF 10% 25V
* C1705 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1706 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1707 1-116-720-11 CERAMIC CHIP 10uF 20% 6.3V
< JACK/CONNECTOR >
CN1701 1-843-541-11 OPTICAL RECEIVER JACK (TV DIGITAL IN)
CN1702 1-817-201-51 CONNECTOR, FFC/FPC 9P
CN1703 1-573-290-21 PIN, CONNECTOR (1.5 mm) (SMD) 4P
< JACK >
* J1701 1-842-576-11 MINI JACK (RA) (ANALOG IN)
< TRANSISTOR >
Q001 6-553-292-01 TRANSISTOR 2SCR502UBTL
< RESISTOR >
R1702 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
AMP DISPLAY IO
