Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-ST9
86
R1703 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R1704 1-218-941-81 METAL CHIP 100 5% 1/16W
R1707 1-218-967-11 METAL CHIP 15K 5% 1/16W
R1708 1-218-967-11 METAL CHIP 15K 5% 1/16W
R1709 1-218-941-81 METAL CHIP 100 5% 1/16W
R1710 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1711 1-218-935-11 METAL CHIP 33 5% 1/16W
R1716 1-218-929-11 METAL CHIP 10 5% 1/16W
R1719 1-218-929-11 METAL CHIP 10 5% 1/16W
R1720 1-218-968-11 METAL CHIP 18K 5% 1/16W
R1721 1-218-968-11 METAL CHIP 18K 5% 1/16W
R1722 1-218-935-11 METAL CHIP 33 5% 1/16W
*************************************************************
A-2058-288-A KEY BOARD, COMPLETE
*******************
When the KEY board is defective, replace the complete mounted board.
*************************************************************
9 A-2071-285-A MB1406 BOARD, COMPLETE (SV) (US, CND)
(See Note 1)
9 A-2071-287-A MB1406 BOARD, COMPLETE (SV) (AEP)
(See Note 1)
9 A-2071-288-A MB1406 BOARD, COMPLETE (SV) (UK)
(See Note 1)
9 A-2071-289-A MB1406 BOARD, COMPLETE (SV) (RU)
(See Note 1)
9 A-2071-290-A MB1406 BOARD, COMPLETE (SV) (SP)
(See Note 1)
9 A-2071-291-A MB1406 BOARD, COMPLETE (SV) (AUS)
(See Note 1)
9 A-2071-293-A MB1406 BOARD, COMPLETE (SV) (CH)
(See Note 1)
9 A-2071-294-A MB1406 BOARD, COMPLETE (SV) (TW)
(See Note 1)
9 A-2071-298-A MB1406 BOARD, COMPLETE (SV) (LA)
(See Note 1)
**********************
When the MB1406 board is defective, replace the complete mounted board.
*************************************************************
A-2054-811-A POWER BOARD, COMPLETE
(AEP, RU, UK, AUS, CH, SP)
A-2059-212-A POWER BOARD, COMPLETE (US, CND, TW)
A-2075-345-A POWER BOARD, COMPLETE (LA)
**********************
7-685-646-71 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
0 C902 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(Except US, CND, TW) (See Note 2)
0 C903 1-112-871-51 CERAMIC 0.0022uF 20% 250V
(Except US, CND, TW) (See Note 2)
0 C905 1-114-594-21 FILM 0.22uF 10% 310V
(See Note 2)
0 C907 1-116-397-21 FILM 0.33uF 10% 310V
(Except US, CND, TW) (See Note 2)
0 C914 1-118-996-11 ELECT 390uF 20% 200V
(US, CND, TW) (See Note 2)
0 C915 1-118-715-11 ELECT (BLOCK) 100uF 20 % 450V
(AEP, RU, UK, AUS, CH, SP)
0 C930 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
0 C931 1-164-217-91 CERAMIC CHIP 150PF 5% 50V
(US, CND, TW)
0 C931 1-164-218-91 CERAMIC CHIP 180PF 5% 50V
(Except US, CND, TW)
0 C932 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C933 1-116-717-11 CERAMIC CHIP 10uF 20% 10V
0 C934 1-116-729-11 CERAMIC CHIP 2.2uF 20% 10V
0 C935 1-117-824-11 FILM 2200PF 3% 1.5KV
(US, CND, TW)
0 C936 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
0 C937 1-116-874-11 CERAMIC CHIP 10uF 10% 35V
0 C938 1-112-841-11 FILM 820PF 3% 1.5KV
(Except US, CND, TW)
0 C939 1-116-034-92 FILM 0.0033uF 5% 400V
(See Note 2)
0 C940 1-112-869-51 CERAMIC 470PF 10% 250V
(US, CND, TW)
0 C941 1-112-235-21 ELECT 330uF 20% 25V
C951 1-116-739-11 CERAMIC CHIP 0.47uF 10% 50V
C952 1-118-291-11 CERAMIC CHIP 100PF 5% 50V
C967 1-114-994-11 ELECT 2200uF 20% 35V
(See Note 2)
C968 1-118-361-11 CERAMIC CHIP 0.1uF 10% 50V
C970 1-112-244-11 ELECT 2200uF 20% 25V
(See Note 2)
C971 1-118-345-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-112-245-21 ELECT 47uF 20% 35V
C977 1-112-245-21 ELECT 47uF 20% 35V
C980 1-112-245-21 ELECT
47uF 20% 35V
0 C988 1-114-721-21 FILM 0.1uF 10% 310V
(US, CND, TW) (See Note 2)
0 C989 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND, TW) (See Note 2)
0 C990 1-112-870-51 CERAMIC 0.001uF 20% 250V
(US, CND, TW) (See Note 2)
C992 1-118-373-11 CERAMIC CHIP 0.01uF 10% 50V
0 C993 1-116-772-11 ELECT (BLOCK) 180uF 20% 450V (LA)
C994 1-112-241-11 ELECT 1000uF 20% 25V
(See Note 2)
< CONNECTOR >
0* CN901 1-793-660-11 PIN, CONNECTOR (PC BOARD) 3P
< DIODE >
0 D901 8-719-077-77 DIODE D3SB60F3 (See Note 2)
0 D930 6-503-021-01 DIODE DZ2J10000L
0 D931 8-719-083-71 DIODE UDZSUSTE-1730B
0 D932 6-502-975-01 DIODE DZ2J15000L
0 D934 6-502-961-01 DIODE DA2J10100L
0 D936 6-501-119-01 DIODE RR264M-400
0 D937 6-501-119-01 DIODE RR264M-400
0 D938 6-503-731-01 DIODE SARS10
0 D939 6-503-037-01 DIODE DZ2J24000L
0 D941 8-719-083-71 DIODE UDZSUSTE-1730B
0 D942 6-503-775-01 DIODE CRH02 (T5R, SONY, XM)
D951 6-502-961-01 DIODE DA2J10100L
D952 6-503-037-01 DIODE DZ2J24000L
D965 6-504-084-01 DIODE LQA20T200C
D967 6-503-978-01 DIODE RB068L100TE25
0 D972 6-502-264-01 DIODE KDZTR18B
D973 8-719-083-71 DIODE UDZSUSTE-1730B
0 D974 6-503-036-01 DIODE DZ2J220M0L (US, CND, TW)
0 D974 6-503-037-01 DIODE DZ2J24000L (Except US, CND, TW)
0 D975 6-502-961-01 DIODE DA2J10100L
Note 1: When the complete MB1406 board is replaced, refer to
“NOTE OF REPLACING THE COMPLETE MB1406
BOARD OR CARD WLAN/BT COMBO” on page 6.
Note 2: When C902, C903, C905, C907, C914, C939, C967, C970, C988, C989,
C990, C994 and D901 on the POWER board are replaced, refer to
“BOND FIXATION OF ELECTRIC PARTS” on page 9.
IO KEY MB1406 POWER
Ver. 1.1
