Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-ST9
87
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
0 F931 1-523-085-11 FUSE (2.5 A/250 V)
< IC >
0 IC930 6-720-460-01 IC STR-Y6735 (US, CND, TW)
0 IC930 6-721-976-01 IC STR-Y6766B (Except US, CND, TW)
IC931 6-716-865-01 IC MM1431FNRE
< COIL >
L966 1-456-606-11 COIL, CHOKE 10uH
L967 1-481-175-21 INDUCTOR 4.7uH
< LINE FILTER >
0 LF901 1-445-944-11 TRANSFORMER, LINE FILTER
(Except US, CND, TW)
0 LF901 1-460-693-11 LINE FILTER TRANSFORMER (US, CND, TW)
< PHOTO COUPLER >
0 PH930 6-600-883-01 PHOTO COUPLER EL816S1 (B) (TA) (DTE-S)
< TRANSISTOR >
0 Q930 8-729-056-46 TRANSISTOR 2SC5053T100Q
0 Q931 6-552-949-01 TRANSISTOR LTC044EUBFS8TL
Q951 6-553-292-01 TRANSISTOR 2SCR502UBTL
< RESISTOR >
0 R901 1-240-938-51 METAL 1.5M 5% 0.5W F
0 R914 1-248-270-15 FUSIBLE 0.33 10% 1W F
0 R935 1-216-825-91 METAL CHIP 2.2K 5% 1/10W
0 R936 1-216-841-91 METAL CHIP 47K 5% 1/10W
0 R937 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R938 1-216-838-91 METAL CHIP 27K 5% 1/10W
0 R944 1-215-927-51 METAL OXIDE 47K 5% 3W F
(US, CND, TW) (See Note)
0 R944 1-215-929-51 METAL OXIDE 100K 5% 3W F
(Except US, CND, TW) (See Note)
0 R945 1-216-809-91 METAL CHIP 100 5% 1/10W
0 R947 1-216-793-91 METAL CHIP 4.7 5% 1/10W
R951 1-216-837-11 METAL CHIP 22K 5% 1/10W
R952 1-216-841-11 METAL CHIP 47K 5% 1/10W
R953 1-216-809-11 METAL CHIP 100 5% 1/10W
R955 1-216-809-11 METAL CHIP 100 5% 1/10W
0 R956 1-257-620-11 RES-CHIP 0.11 1% 2W
(US, CND, TW)
0 R956 1-257-631-11 RES-CHIP 0.18 1% 2W
(Except US, CND, TW)
R965 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-849-11 METAL CHIP 220K 5% 1/10W
R976 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R977 1-218-887-11 METAL CHIP 47K 0.5% 1/10W
R978 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R987 1-216-821-11 METAL CHIP 1K 5% 1/10W
0 R989 1-216-793-91 METAL CHIP 4.7 5% 1/10W
0 R990 1-216-793-91 METAL CHIP 4.7 5% 1/10W
0 R991 1-216-864-91 SHORT CHIP 0
0 R992 1-216-821-91 METAL CHIP 1K 5% 1/10W
(US, CND, TW)
0 R992 1-216-833-91 METAL CHIP 10K 5% 1/10W
(Except US, CND, TW)
0 R997 1-216-864-91 SHORT CHIP 0 (US, CND, TW)
< TRANSFORMER >
0 T901 1-697-327-11 CONVERTER TRANSFORMER (01C313)
(US, CND, TW)
0 T901 1-697-427-11 CONVERTER TRANSFORMER (01C421)
(Except US, CND, TW)
< THERMISTOR >
0 TH901 1-811-315-31 POWER THERMISTOR (See Note)
< VARISTOR >
0 VDR901 1-811-165-31 VARISTOR (TVR10471-D) (See Note)
*************************************************************
A-2054-816-A REPEATER_REP1 BOARD, COMPLETE
******************************
When the REPEATER_REP1 board is defective, replace the complete mounted
board.
*************************************************************
A-2058-292-A REPEATER_REP2 BOARD, COMPLETE
******************************
When the REPEATER_REP2 board is defective, replace the complete mounted
board.
*************************************************************
USB BOARD
**********
< CAPACITOR >
C1501 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
C1502 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1503 1-118-412-11 CERAMIC CHIP 220PF 10% 50V
< CONNECTOR >
CN1501 1-779-993-11 PIN, CONNECTOR (PWB) 5P
* CN1502 1-843-199-11 USB CONNECTOR (
)
< DIODE >
D1501 6-500-400-01 DIODE BAV99-215
D1502 6-500-400-01 DIODE BAV99-215
< FERRITE BEAD >
FB1501 1-481-467-11 BEAD, FERRITE (CHIP)
FB1502 1-481-467-11 BEAD, FERRITE (CHIP)
< RESISTOR >
R1502 1-218-990-81 SHORT CHIP 0
R1504 1-216-864-11 SHORT CHIP 0
*************************************************************
WS BOARD
*********
< CAPACITOR >
* C1402 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1403 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C1404 1-116-714-11 CERAMIC CHIP 22uF 20% 6.3V
* C1406 1-116-738-11 CERAMIC CHIP 1uF 10% 6.3V
* C1408 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
Note: When R944, TH901 and VDR901 on the POWER board are re-
placed, refer to “BOND FIXATION OF ELECTRIC PARTS” on
page 9.
POWER REPEATER_REP1 REPEATER_REP2 USB WS
