Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HT-ST9
88
* C1409 1-118-035-11 CERAMIC CHIP 0.1uF 10% 25V
C1412 1-164-866-11 CERAMIC CHIP 47PF 5% 50V
C1414 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
C1415 1-100-354-21 ELECT CHIP 220uF 20% 6.3V
< CONNECTOR >
* CN1401 1-793-152-21 CONNECTOR 11P
CN1402 1-843-711-11 CONNECTOR, FFC/FPC (LIF) 26P
< COIL >
L1401 1-400-789-21 INDUCTOR 2.2uH
< RESISTOR >
R1402 1-218-990-81 SHORT CHIP 0
R1403 1-218-990-81 SHORT CHIP 0
R1409 1-218-990-81 SHORT CHIP 0
R1411 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1413 1-218-933-11 METAL CHIP 22 5% 1/16W
R1414 1-218-965-11 METAL CHIP 10K 5% 1/16W
R1417 1-218-990-81 SHORT CHIP 0
R1418 1-218-990-81 SHORT CHIP 0
R1420 1-218-990-81 SHORT CHIP 0
R1421 1-218-933-11 METAL CHIP 22 5% 1/16W
R1422 1-218-933-11 METAL CHIP 22 5% 1/16W
R1423 1-218-933-11 METAL CHIP 22 5% 1/16W
R1424 1-218-933-11 METAL CHIP 22 5% 1/16W
R1425 1-218-933-11 METAL CHIP 22 5% 1/16W
R1426 1-218-933-11 METAL CHIP 22 5% 1/16W
R1432 1-218-990-81 SHORT CHIP 0
*************************************************************
MISCELLANEOUS
**************
0 AC1 1-834-966-42 POWER-SUPPLY CORD (AEP, RU, LA, SP)
0 AC1 1-835-068-21 CORD, POWER (AUS)
0 AC1 1-837-308-12 CORD, POWER-SUPPLY (US, CND)
0 AC1 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 AC1 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 AC1 1-839-999-21 POWER-SUPPLY CORD (UK)
FFC1 9-833-606-99 WIRE KIT (FFC/SA-ST9) (28P) (See Note 2)
FFC2 9-833-606-99 WIRE KIT (FFC/SA-ST9) (9P) (See Note 2)
FFC3 9-833-606-99 WIRE KIT (FFC/SA-ST9) (26P) (See Note 2)
FFC4 9-833-606-99 WIRE KIT (FFC/SA-ST9) (22P) (See Note 2)
FFC5 9-833-606-99 WIRE KIT (FFC/SA-ST9) (6P) (See Note 2)
NFC1 8-989-602-00 RC-S730 (NFC module)
OLED1 1-812-047-11 OLED DISPLAY
RF1 1-492-700-61 RF MODULATOR (WS001)
SP1 1-859-073-11 LOUDSPEAKER (18 mm, WITH BRIDGE)
(Tweeter (Front L-ch))
SP2 1-859-076-21 LOUDSPEAKER (6.5 cm)-076-21
(Woofer (Front L-ch))
SP3 1-859-073-11 LOUDSPEAKER (18 mm, WITH BRIDGE)
(Tweeter (Front R-ch))
SP4 1-859-076-21 LOUDSPEAKER (6.5 cm)-076-21
(Woofer (Front R-ch))
SP5 1-859-076-11 LOUDSPEAKER (6.5 cm)-076-11 (Surround (R-ch))
SP6 1-859-076-11 LOUDSPEAKER (6.5 cm)-076-11 (Surround (L-ch))
SP7 1-859-076-11 LOUDSPEAKER (6.5 cm)-076-11
(Surround back (L-ch))
SP8 1-859-076-11 LOUDSPEAKER (6.5 cm)-076-11
(Surround back (R-ch))
SP9 1-859-076-21 LOUDSPEAKER (6.5 cm)-076-21 (Woofer (Center))
SP10 1-859-073-21 LOUDSPEAKER (18 mm, WITH BRIDGE)
(Tweeter (Center))
SPC1 1-848-696-11 CONNECTION CABLE WITH SPEAKER (for L-ch)
SPC2 1-848-696-21 CONNECTION CABLE WITH SPEAKER (for R-ch)
SPC3 1-848-698-11 CONNECTION CABLE WITH SPEAKER
(for Surround L/R)
SPC4 1-848-697-11 CONNECTION CABLE WITH SPEAKER
(for Center, Surround back L/R)
WIFI1 1-458-765-21 CARD WLAN/BT COMBO (See Note 1)
WR1 9-833-606-82 WIRE KIT (USB)
WR2 9-833-606-84 WIRE KIT (WS)
WR3 9-833-606-83 WIRE KIT (WIFI/BT)
*************************************************************
Note 1: When the card WLAN/BT combo is replaced, refer to “NOTE
OF REPLACING THE COMPLETE MB1406 BOARD OR
CARD WLAN/BT COMBO” on page 6.
Note 2: As for WIRE KIT (FFC/SA-ST9), all fl at fl exible cables (Ref.
No. FFC1, FFC2, FFC3, FFC4, FFC5) will be 1 set.
WS
Ver. 1.1
