Sony SLV-D910AZ - Disassembly and Reassembly; Cabinet and PCB; Cabinet Top Removal; Bottom Cover Removal

2-1
2-1-2 Bottom Cover Removal
ΠRELEASE 12 HOOKS
<SLV-D910>
ΠRELEASE 12 HOOKS
<SLV-D950>
2. DISASSEMBLY AND REASSEMBLY
2-1 CABINET AND PCB
Fig. 2-1 Cabinet Top Removal
Fig. 2-2 Bottom Cover Removal
2-1-1 Cabinet Top Removal 2-1-3 Ass’y Front Panel Removal
Fig. 2-3 Ass’y Front Panel Removal
2-1-4 Function PCB Removal
Fig. 2-4 Function PCB Removal
´ Lift up the Cabinet Top in the direction of arrow.
ΠREMOVE
3 SCREWS
ΠRELEASE 4 HOOKS
´ RELEASE 3 HOOKS
(Top View)
(Bottom View)
ΠRELEASE 1 HOOK
SLV-D910AZ/D910B/D910E/D910N/D910R/
D950B/D950E/D950GI
