Sony SLV-D910AZ - Sub Chassis Removal

2-25
2-6-4 Sub Chassis Removal
1) Remove the Soldering of Motor Feed (+, - wire) 1.
2) Remove the 4 Screws 2.
3) Lift up the Ass’y Brkt Deck 3.
Fig. 2-47 Sub Chassis Removal
2 4 SCREWS
3 ASSY-BRAK DECK
1 SOLDERING OF
MOTOR FEED (+, - WIRE)
