Sony SLV-ED1PL - 2-9. CIRCUIT BOARDS LOCATION

2-4
2-9. CIRCUIT BOARDS LOCATION
ED1
2-4 E
ED4/ED7/ED8
MA-323
(
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL, TUNER
)
DS-80
(MODE CONTROL)
POWER BLOCK (HS-921SF)
(POWER SUPPLY)
MA-323
(
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL, TUNER
)
DM-76
(MODE CONTROL)
POWER BLOCK (HS-921SF1)(ED4)
POWER BLOCK (SR-708) (ED7/ED8)
(POWER SUPPLY)
NK-11 (ED7)
(KOREAN STEREO)
MF-312
(
MODE CONTROL,
)
FRONT IN
