8-8
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
8-2. ELECTRICAL PARTS LIST
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DM-76 DS-80 MA-323
* A-6791-586-A DM-76 BOARD, COMPLETE (ED8)
* A-6791-588-A DM-76 BOARD, COMPLETE (ED4/ED7)
*********************
(Ref.No.1,000 Series)
< CONNECTOR >
CN451 1-774-471-41 CONNECTOR, FFC/FPC 5P (ED8)
CN452 1-691-066-21 HOUSING, CONNECTOR 7P
< RESISTOR >
R442 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R443 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R444 1-216-295-00 METAL CHIP 0 5% 1/10W
R445 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R446 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R447 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S441 1-762-196-21 SWITCH, TACTILE (EJECT)
S442 1-762-196-21 SWITCH, TACTILE (REW) (ED8)
S443 1-762-196-21 SWITCH, TACTILE (FF) (ED8)
S444 1-762-196-21 SWITCH, TACTILE (PAUSE)
S445 1-762-196-21 SWITCH, TACTILE (REC)
S447 1-762-196-21 SWITCH, TACTILE (REW) (ED4/ED7)
S448 1-762-196-21 SWITCH, TACTILE (FF) (ED4/ED7)
S449 1-762-196-21 SWITCH, TACTILE (STOP) (ED4/ED7)
S450 1-762-196-21 SWITCH, TACTILE (PLAY) (ED4/ED7)
* A-6794-527-A DS-80 BOARD, COMPLETE (ED1)
*********************
(Ref.No.2,000 Series)
< CONNECTOR >
CN452 1-691-066-21 HOUSING, CONNECTOR 7P
< RESISTOR >
R451 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R452 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R453 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S450 1-571-977-11 SWITCH, TACTILE (FF)
S452 1-571-977-11 SWITCH, TACTILE (PLAY)
S453 1-571-977-11 SWITCH, TACTILE (STOP)
S455 1-571-977-11 SWITCH, TACTILE (REW)
* A-6791-629-A MA-323 BOARD, COMPLETE (ED8)
* A-6791-677-A MA-323 BOARD, COMPLETE (ED7)
* A-6791-678-A MA-323 BOARD, COMPLETE (ED4)
* A-6791-640-A MA-323 BOARD, COMPLETE (ED1)
**********************
(Ref.No.2,000 Series)
* 3-960-273-01 SPACER, TOP END
* 3-960-274-01 SPACER, LED
* 3-966-865-01 BASE, INDICATION TUBE
< CAPACITOR >
C100 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C101 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C102 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C103 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C104 1-128-057-11 ELECT 330uF 20% 6.3V
C106 1-124-589-11 ELECT 47uF 20% 16V
C108 1-163-259-91 CERAMIC CHIP 220PF 5% 50V
C109 1-124-589-11 ELECT 47uF 20% 16V
C111 1-124-589-11 ELECT 47uF 20% 16V
(ED1)
C112 1-104-905-11 CAPACITOR 0.22F 5.5V
C113 1-163-253-11 CERAMIC CHIP 120PF 5% 50V
C114 1-124-248-00 ELECT 22uF 20% 35V
C115 1-126-157-11 ELECT 10uF 20% 16V
C116 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C117 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C119 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
(ED7/ED8)
C120 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C121 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C122 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C123 1-126-925-11 ELECT 470uF 20% 10V
C124 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C125 1-124-589-11 ELECT 47uF 20% 16V
C126 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C127 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
(ED1)
C128 1-117-720-11 CERAMIC CHIP 4.7uF 10V
To Next Page
