SLV-ED1/ED4/ED7/ED8
4-8
MA-323
(
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL, TUNER
)
DS-80
(MODE CONTROL)
POWER BLOCK (HS-921SF)
(POWER SUPPLY)
MA-323
(
VIDEO, AUDIO, I/O,
SERVO/SYSTEM CONTROL, TUNER
)
DM-76
(MODE CONTROL)
POWER BLOCK (HS-921SF1)(ED4)
POWER BLOCK (SR-708) (ED7/ED8)
(POWER SUPPLY)
NK-11 (ED7)
(KOREAN STEREO)
MF-312
(
MODE CONTROL,
)
FRONT IN
MA-323 BOARD
CN101 F-12
CN102 E-3
CN103 H-6
CN104 H-12
CN105 I-13
CN161 I-12
CN301 B-6
CN302 B-5
CN341 C-12
CN423 D-12
CN424 I-1
CN501 A-9
CN502 B-10
CN600 G-1
CN751 H-13
D102 F-7
D103 F-11
D104 I-5
D105 J-13
D106 G-9
D130 I-4
D163 I-6
D164 I-7
D165 H-6
D305 B-5
D306 D-12
D307 B-5
D401 J-1
D402 E-8
D403 E-7
D600 H-1
D601 H-1
D602 H-1
D603 I-2
D604 H-5
D701 C-12
D702 C-12
D704 E-12
D908 A-4
D909 A-4
IC130 I-4
IC161 H-8
IC162 I-11
IC163 H-11
IC201 D-5
IC202 E-5
IC203 D-3
IC340 B-11
IC360 D-10
IC400 J-9
IC420 I-7
IC501 B-9
IC600 I-2
IC601 J-2
IC602 D-9
IC750 H-13
IC901 B-2
Q100 F-11
Q101 F-3
Q102 G-6
Q103 H-6
Q105 H-9
Q201 E-4
Q202 D-7
Q204 C-3
Q205 C-3
Q207 D-7
Q208 C-6
Q209 D-7
Q210 D-6
Q301 B-6
Q302 B-6
Q303 B-6
Q305 C-7
Q307 C-6
Q308 C-6
Q311 B-6
Q312 B-6
Q330 B-2
Q331 C-2
Q332 B-6
Q400 E-6
Q402 E-8
Q501 B-9
Q600 G-2
Q601 G-2
Q602 I-1
Q603 I-1
Q701 C-13
Q703 E-13
Q754 H-13
Q901 A-7
