STR-DA5500ES
8
MAIN BOARD SERVICE POSITION
A-AUDIO BOARD SERVICE POSITION
• Please connect following extension jig.
Jig No. Part No. Pitch (mm) Cores Length (mm)
qs
J-2501-254-A 1.25 8 300
qd
J-2501-258-A 1.25 16 300
Connect extension jig qs to the
A-AUDIO board (CN726) and
CONTROL board (CN2508).
A-AUDIO board
(CN726)
CONTROL board
(CN2503)
insulating sheet
A-AUDIO board
(CN601)
CONTROL board
(CN2508)
Connect extension jig qd to the
A-AUDIO board (CN601) and
CONTROL board (CN2503).
MAIN board
insulating sheet
