STR-DA6400ES
167
Pin No. Pin Name I/O Description
63 AGND - Ground terminal
64 AVCC33 - Power supply terminal (+3.3V)
65 R1X1- I TMDS data (negative) input from the HDMI input selector
66 R1X1+ I TMDS data (positive) input from the HDMI input selector
67 AGND - Ground terminal
68 AVCC33 - Power supply terminal (+3.3V)
69 R1X2- I TMDS data (negative) input from the HDMI input selector
70 R1X2+ I TMDS data (positive) input from the HDMI input selector
71 AGND - Ground terminal
72 AVCC18 - Power supply terminal (+1.8V)
73 IOGND - Ground terminal
74 IOVCC33 - Power supply terminal (+3.3V)
75 MUTEOUT O Audio muting control signal output terminal
76, 77 RSVDNC - Not used
78 SPDIF O
S/PDIF signal output to the digital audio interface receiver, HDMI transmitter, DSP1 and DSP
controller
79 CGND - Ground terminal
80 CVCC18 - Power supply terminal (+1.8V)
81 to 84 SD0 to SD3 O PCM audio signal output to the HDMI transmitter and DSP1
85 WS O L/R sampling clock signal output to the HDMI transmitter, DSP1 and DSP2
86 SCK O Bit clock signal output to the HDMI transmitter, DSP1 and DSP2
87 IOGND - Ground terminal
88 IOVCC33 - Power supply terminal (+3.3V)
89 MCLK O
Master clock signal output to the D/A converter (for video section), HDMI transmitter, DSP1
and DSP2
90 CGND - Ground terminal
91 CVCC18 - Power supply terminal (+1.8V)
92 DVCC18 - Power supply terminal (+1.8V)
93 DGND2 - Ground terminal
94 XTALOUT O System clock output terminal (28.322 MHz)
95 XTALIN I System clock input terminal (28.322 MHz)
96 XTALVCC - Power supply terminal (+3.3V)
97 REGVCC - Power supply terminal (+3.3V)
98 RSVDNC - Not used
99 RSVDL - Not used
100 RESET# I Reset signal input from the video system controller "L": reset
101 SCDT - Not used
102 INT O Interrupt signal output to the video system controller
103 IOGND - Ground terminal
104 IOVCC33 - Power supply terminal (+3.3V)
105 CI2CA - Not used
106 CGND - Ground terminal
107 CVCC18 - Power supply terminal (+1.8V)
108 to 111 Q35 to Q32 O Serial data output to the HDMI transmitter and video processor1
112 IOGND - Ground terminal
113 IOVCC33 - Power supply terminal (+3.3V)
114 to 117 Q31 to Q28 O Serial data output to the HDMI transmitter and video processor1
118 CGND - Ground terminal
119 CVCC18 - Power supply terminal (+1.8V)
120, 121 Q27, Q26 O Serial data output to the HDMI transmitter and video processor1
122, 123 Q25, Q24 O Serial data output to the HDMI transmitter
124 IOGND - Ground terminal
125 IOVCC33 - Power supply terminal (+3.3V)
126 to 129 Q23 to Q20 O Serial data output to the HDMI transmitter and video processor1
130 CGND - Ground terminal
131 CVCC - Power supply terminal (+1.8V)
