STR-DA6400ES
SECTION 7
EXPLODED VIEWS
1 4-974-510-11 SCREW (+BV 3X8 CU)
2 3-701-748-00 CLAMP
3 1-500-082-11 CLAMP, SLEEVE FERRITE
4 4-227-843-03 SCREW (TP), FLAT HEAD
5 2-580-630-01 SCREW, +BVST 4X8
6 2-668-102-11 CASE
7 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
0 F1405 1-532-506-33 FUSE (T6.3AL/250V)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
Note:
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• The mechanical parts with no reference
number in the exploded views are not sup-
plied.
• Color Indication of Appearance Parts Ex-
ample:
KNOB, BALANCE (WHITE) . . . (RED)
↑ ↑
Parts Color Cabinet’s Color
F1405
not supplied
(DCDC2 board)
not supplied
(FILTER board)
1
1
1
1
1
7
1
3
2
2
4
4
5
5
6
not
supplied
not supplied
not supplied
not supplied
not supplied
DIGITAL board section
"
#
"
#
not supplied
(DCDC1 board)
1
7-1. CASE SECTION
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
