STR-DA6400ES
19
two screws (BVTP3 × 8)
two screws
(BVTP3 × 8)
seven screws (B3 × 6)
four connectors
(CN3509, CN3607,
CN3609, CN3610)
lead wire
(NETWORK board: CN8200,
D VIDEO board: CN3608)
connector
(CN3523)
RE connector
(CN8006)
RI two screws
(BVTP3 × 8)
RL three screws
(BVTP3 × 8)
XB two screws
(BVTP3 × 8)
RG two screws
(BVTP3 × 8)
two HS holders
two HS holders
bracket (HDMI-A64)
X bracket (DMPORT-A64)
RM two clamps
(L35)
XT clamp (L35)
XE bracket (DM-HD)
R heatsink (S58F)
R heatsink (S58F)
RB radiation sheet (F)
RB radiation sheet (F)
RT D VIDEO board
XG NETWORK board
RH 03P insulating bushing
five screws
(BVTP3 × 8)
RK
connector
(CN3507)
RE two connectors
3-5. D VIDEO/NETWORK BOARDS
3-4. DSP/DIGITAL/CIS/CONTROL BOARDS
RB three screws
(BVTP3 × 8)
"
#
"
#
$
$
RE DIGITAL board
RT bracket (digital)
two screws
(BVTP3 × 8)
XH CONTROL
board
RH two screws
(BVTP3 × 8)
RL two screws
(BVTP3 × 8)
RK screws
(BVTP3 × 8)
XT two screws
(BVTP3 × 8)
XG two brackets
(control)
XE clamp (L35)
XB three connectors
(CN2516, CN2519, CN2520)
D CONNECT board
RI CIS board
four connectors
(CN2403, CN2404,
CN2405, CN2406)
RM ten connectors
(CN2502, CN2503, CN2504,
CN2505, CN2507, CN2508,
CN2509, CN2511, CN2513,
CN2515)
eight screws
(BVTP3 × 8)
connector
(CN3571)
two connectors
(CN2204, CN2207)
connector
(CN2206)
R DSP board
four screws
(BVTP3 × 8)
RG wire (flat type) (13 core)
(CIS board (CN807),
D VIDEO board (CN2510))
