Sony STR-DA6400ES - ANALOG Board; Heat Sink Block

STR-DA6400ES
21
3-8. ANALOG BOARD

screw
(B3
×
6)

seven screws
(BVTP3
×
8)

screw
(BVTP3
×
8)

three connectors
(CN605, CN606, CN608)

wire (flat type) (9core)
(CN603)

screw
(BVTP3
×
8)

bracket (side)
R
ANALOG board

reinforcement
(main)

3-9. HEAT SINK BLOCK

connector
(CN1405)

two connectors
(CN1207, CN1209)

two connectors
(CN1205, CN1206)

seven screws
(BV3
×
8 CU)

CONNECTOR1 board

heat sink block

CONNECTOR2 board
