Sony STR-DA6400ES - Front Panel Block; A-VIDEO Board

STR-DA6400ES
20
3-6. FRONT PANEL BLOCK
3-7. A-VIDEO BOARD

two screws
(BVTP3
×
8)


two connectors
(ANALOG board: CN607,
A-VIDEO board: CN6003)

connector
(CN1)

two screws
(BVTP3
×
8)

two terminals

five screws
(BVTP3
×
8)
R
front panel block

Cut the clamp.

clamp filter (ferrite core)

two screws
(BV3
×
8 CU)

eight screws
(BVTP3
×
8)

screw
(BVTP3
×
8)

screw
(BVTP3
×
8)

bracket (WB)

A-VIDEO board

connector
(CN6008)

