STR-DA6400ES
190
DISPLAY BOARD IC105 uPD78F0527GB(S)-UET-A (UPDATE SIGNAL CONVERTER)
Pin No. Pin Name I/O Description
1 to 4 NO USE - Not used
5 RESET I Reset signal input from the system controller
6, 7 NO USE - Not used
8 FLMD0 I Serial data input terminal
9 OSC OUT O System clock output terminal (5MHz)
10 OSC IN I System clock input terminal (5MHz)
11 REGC I Connected to the external capacitor
12 VSS - Ground terminal
13 VDD - Power supply terminal (+3.2V)
14 to 16
BAUDRATE3 to
BAUDRATE1
I Baud rate setting terminal Not used
17 NO USE - Not used
18 P33 O Serial data output terminal
19 to 30 NO USE - Not used
31 IR OUT O IR signal output terminal
32 NO USE - Not used
33 NO USE I Update signal input terminal Not used
34 NO USE O Update signal output terminal Not used
35 NO USE - Not used
36 UART IN I IR learning UCOM UART signal input from the system controller
37 UART OUT O IR learning UCOM UART signal output to the system controller
38 AVREF I Reference voltage (+3.2V) input terminal
39 AVSS - Ground terminal
40 to 47 NO USE - Not used
48 LEARN LED - Not used
49, 50 NO USE - Not used
51 LEARN CIR ON O Learning circuit on signal output terminal
52 LEARN IR IN I Learning IR signal input to the wave shapper
