STR-DA6400ES
189
Pin No. Pin Name I/O Description
161 GND - Ground terminal
162 +5V - Power supply terminal (+3.3V)
163
VIDEO UCOM
ENDFLAG
I End fl ag input from the video system controller
164 VIDEO UCOM MODE O Mode setting signal output to the video system controller
165 RDS_CLK I RDS serial data transfer clock signal input terminal Not used
166 VUCOM-BUSY I Busy signal input from the video system controller
167 VUCOM-RST O Reset signal output to the video system controller "L": reset
168 FSRATE1 I L/R sampling clock signal input from the digital audio interface receiver or HDMI receiver
169 PNX RESET O Reset signal output to the connected media processor
170 232C-SEL2 O Data selection signal output terminal
171 XM-RESET O Reset signal output to the XM receiver "L": reset
172 XM-DA_LAT O Serial data latch pulse signal output to the D/A converter (for XM section)
173 XM_POWER O Power supply on/off control signal output terminal for XM section "H": power on
174 DEV I2C SDA I/O Two-way data bus with the EEPROM
175 DEV I2C SCL O Serial data transfer clock signal output to the EEPROM
176 +5V - Power supply terminal (+3.3V)
