Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA6400ES
217217
CN3512 1-820-735-31 HDMI CONNECTOR
(HDMI ASSIGNABLE (INPUT ONLY) OUT B)
CN3523 1-785-102-11 PIN, CONNECTOR (3.96mm PITCH) 4P
CN3571 1-815-954-21 PIN, CONNECTOR (PC BOARD) 13P
CN3603 1-785-125-21 CONNECTOR 6P
CN3605 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
CN3607 1-770-468-21 PIN, CONNECTOR (PC BOARD) 10P
CN3608 1-770-470-21 PIN, CONNECTOR (PC BOARD) 6P
CN3609 1-779-992-11 PIN, CONNECTOR (PWB) 8P
CN3610 1-816-296-21 PIN, CONNECTOR (PC BOARD) 9P
CN3611 1-764-250-11 PIN, CONNECTOR (PC BOARD) 4P
< DIODE >
D3500 6-501-817-01 DIODE MA2J1110GLS0
D3501 6-501-817-01 DIODE MA2J1110GLS0
D3502 6-501-817-01 DIODE MA2J1110GLS0
D3511 8-719-073-81 DIODE EC21QS06-TE12L
D3512 6-501-817-01 DIODE MA2J1110GLS0
D3617 8-719-053-18 DIODE 1SR154-400TE-25
D3618 8-719-210-39 DIODE EC10QS-04
D3619 8-719-073-81 DIODE EC21QS06-TE12L
D3620 8-719-210-39 DIODE EC10QS-04
D3621 8-719-073-81 DIODE EC21QS06-TE12L
D3622 8-719-053-18 DIODE 1SR154-400TE-25
D3851 6-501-817-01 DIODE MA2J1110GLS0
D3852 6-501-817-01 DIODE MA2J1110GLS0
D3853 6-500-219-01 DIODE 1SS404 (TPH3)
D3854 6-500-219-01 DIODE 1SS404 (TPH3)
< TERMINAL >
ET3901 1-780-318-11 TERMINAL
ET3902 1-780-318-11 TERMINAL
ET3903 1-780-318-11 TERMINAL
< FERRITE BEAD/JUMPER RESISTOR >
FB3421 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB3422 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB3423 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB3424 1-400-334-21 FERRITE, EMI (SMD) (1608)
FB3426 1-216-864-11 SHORT CHIP 0
FB3502 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3503 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3504 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3505 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3506 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3507 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3508 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3509 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3510 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3511 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3512 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3513 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3558 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3601 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3602 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3603 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3604 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3605 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3606 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3607 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3608 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3609 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3610 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3611 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3612 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3613 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3614 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3615 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3616 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3617 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3618 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3619 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3620 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3621 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3622 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3623 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3624 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3625 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3626 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3627 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3628 1-469-152-11 FERRITE, EMI (SMD) (2012)
FB3629 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3630 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3631 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3632 1-414-234-22 INDUCTOR, FERRITE BEAD
FB3633 1-469-324-21 FERRITE, EMI (SMD) (2012)
FB3634 1-469-139-21 FERRITE, EMI (SMD) (2012)
FB3635 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3636 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3637 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB3638 1-469-152-11 FERRITE, EMI (SMD) (2012)
< COIL/FILTER >
* FL3501 1-813-880-11 COMMON MODE CHOKE COIL
* FL3502 1-813-880-11 COMMON MODE CHOKE COIL
* FL3503 1-813-880-11 COMMON MODE CHOKE COIL
* FL3504 1-813-880-11 COMMON MODE CHOKE COIL
* FL3511 1-813-880-11 COMMON MODE CHOKE COIL
* FL3512 1-813-880-11 COMMON MODE CHOKE COIL
* FL3513 1-813-880-11 COMMON MODE CHOKE COIL
* FL3514 1-813-880-11 COMMON MODE CHOKE COIL
FL3601 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3602 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3603 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3604 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3605 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3606 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3607 1-400-874-11 FILTER, EMI REMOVAL (SMD)
FL3608 1-400-874-11 FILTER, EMI REMOVAL (SMD)
< IC >
IC3503 8-753-282-08 IC CXB1444R-T6
IC3504 8-753-282-08 IC CXB1444R-T6
IC3508 8-759-596-39 IC SN74LV4052APWR
IC3509 6-704-001-01 IC BR24L02F-WSE2
IC3510 8-759-596-39 IC SN74L
V4052APWR
IC3511 (Not supplied) IC SII9135CTU
IC3512 6-704-001-01 IC BR24L02F-WSE2
IC3513 (Not supplied) IC SII9134CTU
IC3514 (Not supplied) IC SII9134CTU
D VIDEO
Note: IC3511, IC3513 and IC3514 cannot exchange with single. When
these parts are damaged, exchange the entire mounted board.
