Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
STR-DA6400ES
249249
C249 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
C250 1-104-665-11 ELECT 100uF 20% 25V
C251 1-104-665-11 ELECT 100uF 20% 25V
< CONNECTOR >
CN241 1-784-923-11 PIN, CONNECTOR 7P
CN242 1-784-924-11 PIN, CONNECTOR 8P
CN243 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN244 1-784-927-11 PIN, CONNECTOR 12P
CN245 1-779-799-11 PIN, CONNECTOR 9P
< DIODE >
D241 6-501-817-01 DIODE MA2J1110GLS0
D242 6-501-817-01 DIODE MA2J1110GLS0
D243 6-501-817-01 DIODE MA2J1110GLS0
D244 6-501-817-01 DIODE MA2J1110GLS0
D245 6-501-817-01 DIODE MA2J1110GLS0
D246 6-501-817-01 DIODE MA2J1110GLS0
< EARTH TERMINAL >
* ET241 1-537-738-21 TERMINAL, EARTH
* ET242 1-537-738-21 TERMINAL, EARTH
< IC >
IC241 6-600-219-01 IC GP1FM313RZ0F (VIDEO 2 IN/
PORTABLE AV IN DIGITAL (OPT))
IC242 8-759-710-97 IC NJM4565M-D
< JACK >
J241 1-770-571-11 JACK BLOCK, PIN (L TYPE) 3P (VIDEO 2 IN/
PORTABLE AV IN AUDIO/VIDEO)
J242 1-820-056-11 SMALL TYPE JACK (AUTO CAL MIC)
< RESISTOR >
R241 1-216-809-11 METAL CHIP 100 5% 1/10W
R243 1-218-285-11 METAL CHIP 75 5% 1/10W
R244 1-216-821-11 METAL CHIP 1K 5% 1/10W
R245 1-216-821-11 METAL CHIP 1K 5% 1/10W
R246 1-216-841-11 METAL CHIP 47K 5% 1/10W
R247 1-216-841-11 METAL CHIP 47K 5% 1/10W
R249 1-216-864-11 SHORT CHIP 0
************************************************************
< DIODE >
D4101 6-501-817-01 DIODE MA2J1110GLS0
D4102 6-501-817-01 DIODE MA2J1110GLS0
< TRANSISTOR >
Q4101 8-729-230-49 TRANSISTOR 2SC2712-YG
Q4102 8-729-230-49 TRANSISTOR 2SC2712-YG
< RESISTOR >
R4101 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
R4102 1-208-445-41 RES-CHIP 2.2K 2% 1/10W
0 R4103 1-249-393-91 CARBON 10 5% 1/4W F
R4104 1-208-462-41 RES-CHIP 10K 2% 1/10W
0 R4105 1-249-393-91 CARBON 10 5% 1/4W F
R4106 1-208-462-41 RES-CHIP 10K 2% 1/10W
0 R4107 1-249-393-91 CARBON 10 5% 1/4W F
0 R4108 1-249-393-91 CARBON 10 5% 1/4W F
0 R4109 1-249-393-91 CARBON 10 5% 1/4W F
0 R4110 1-249-393-91 CARBON 10 5% 1/4W F
< RELAY >
RY4101 1-515-920-11 RELAY (24V)
RY4102 1-515-920-11 RELAY (24V)
< TERMINAL >
0 TM4101 1-780-404-11 TERMINAL BOARD (SP) (8P) (SPEAKERS
SURROUND/SURROUND BACK (ZONE 2))
************************************************************
TEMPERATURE DETECTION BOARD
****************************
< CAPACITOR >
C1909 1-127-888-11 CERAMIC 0.1uF 10% 50V
C1910 1-135-800-11 CERAMIC 1uF 50V
C1913 1-135-800-11 CERAMIC 1uF 50V
< DIODE >
D1906 8-719-109-93 DIODE RD6.2ESB2
< IC >
0 IC1903 6-710-072-01 IC LM61CIZ/LFT2
0 IC1905 6-710-072-01 IC LM61CIZ/LFT2
< RESISTOR >
R1928 1-249-414-11 CARBON 560 5% 1/4W
************************************************************
VIDEO2 BOARD
************
< CAP
ACITOR >
C241 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C242 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C243 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C244 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C245 1-115-414-11 CERAMIC CHIP 820PF 5% 25V
C246 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C247 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C248 1-162-971-11 CERAMIC CHIP 0.001uF 10% 50V
