STR-DA6400ES
25
SPECIAL MENU MODE
Procedure:
1. Press the [POWER] button to turn on the main power, then while pressing the [TONE MODE] button, press the [A.F.D.], [2CH/
A.DIRECT], [MUSIC], [MOVIE] button in order, the message “MENU SPECIALIZED!” appears.
2. Up or down jog switch, the message “<<< SPECIAL >>>” appears.
3. Right jog switch, the item is appears.
4. Each time up or down jog switch, the item is switched in order as follows. Some items can change the content. Display the cursor by
right jog switch, and changing the content by up or down jog switch, and fi x the content by left jog switch when you want to change the
content of the item.
5. To release from this mode, while pressing the [TONE MODE] button, press the [A.F.D.], [2CH/A. DIRECT], [MUSIC], [MOVIE] but-
ton in order again, the message “MENU SPECIALIZED OFF” appears.
Items Display Remark
SYSTEM version display SYSTEM VERSION X.XXX X.XXX: System software version
MAIN Ucom version display
MAIN ##### ∗∗∗ vX. XX
#####: Model
∗∗∗: Destination
X.XX: Main controller software version
Video Ucom version display Video Ucom Ver X. XX X.XX: Video system controller software version
FAROUDJA version display FAROUDJA Ver X. XX X.XX: Video processor software version (main zone)
FAROUDJA (2nd) version display FAROUDJA2ND Ver X. XX X.XX: Video processor software version (2nd zone)
GUI CG-ROM version display GUI CGROM Ver X. XX X.XX: CG-ROM software version
DSP Ucom version display DSP Ucom Ver X. XX X.XX: DSP controller version
DSP serial fl ash version display DSP SFLASH Ver X. XX X.XX: Serial fl ash software version
DSP parallel fl ash version display DSP PFLASH Ver X. XX X.XX: DSP parallel fl ash version
IR learning Ucom version display IR LEARNING Ver X.XX X.XX: IR learning software version
Network IC version display NETWORK PNX Ver X.XX X.XX: Network IC version
DSP debug menu <DSP DEBUG MENU> Not used for the servicing
Network debug menu <NETWORK DEBUG MENU> Menu mode to enter MAC address display. If the jog switch on
the set is pressed, entering the menu, and operating two the
following menu become possible
MAC address display
(Network debug menu)
MAC∗∗:∗∗:∗∗:∗∗:∗∗:∗∗ ∗∗:∗∗:∗∗:∗∗:∗∗:∗∗: MAC address
Zone 4 display ZONE 4 XXXXXXXX Not used for the servicing
FAROUDJA update FAROUDJA UPDATE [XXX] XXX: ON or OFF
HDCP key read HDCP KEY READ [XXX] Not used for the servicing
Learning test LEARNING TEST START? Not used for the servicing
Model/destination change
MODEL [##### ∗∗∗∗ XX]
Not used for the servicing
Video factory menu <VIDEO FACTORY MENU> Menu mode to enter video calibration menu and DDR access
check menu If the jog switch is pressed, entering the menu,
and operating two the following menu become possible
Video calibration
(Video factory menu)
V.CALIBRATION START? Procedure:
1. “DVD” is selected by using [INPUT SELECTOR] dial.
2. Connect a color pattern generator to the COMPONENT
VIDEO ASSIGNABLE (INPUT ONLY) IN2 jack (J6007) on
the A-VIDEO board and DVD VIDEO IN jack (J6003) on the
A-VIDEO board.
3. Input 100% color bars signal from the color pattern generator.
4. Menu that measures individual difference of hardness by
automatic operation in pressing the jog switch, and corrects
reference value. In a measurement once, only one of NTSC/
PAL/HD can be measured, repeat NTSC/PAL/HD calibration
from procedure 4.
“Check XXXX V-IN” at display:
Video signal necessary for the measurement while measuring
it last time was not detected and it became an error
Confi rm the input of the video of the terminal connection etc.,
and measure the jog switch again pressing
DDR access check DDR CHECK [XX] sec XX: Time to do access check on DDR (for design evaluation)
(Video factory menu)
Auto cal mic test SPEAKER OUT [XXXXX] XXXXX: Selection of speaker output audio [SOURCE]: normal-
ly mode, [MIC]: mode that output audio from mic from speaker
FL display fonts test
FL FONT [0x ∗∗ = X] ∗∗: 20 to FE, X: character
