Rotors and accessories
21
Table 2: Rotors for Legend™ RT 120V (differences of 200V / 230V instruments are shown in parentheses)
Rotor designation
Order no.
Micro Liter Rotor
24 x 2.0 ml
7500 3332
Fixed-Angle Rotor
6 x 94 ml
7500 3334
Highconic
®
Rotor
6 x 50 ml
7500 3046
Maximum permissible load [ g ] 24 x 4 6 x 140 6 x 130
Maximum speed nmax [ rpm ] 15 000 12 000 8500
Maximum RCF value at nmax 21 885 16 260 10 016
Radius (max./min.) [ cm ] 8.7 / 5.9 10.1 / 6.3 12.4 / 6.0
Tube angle [ ° ] 45 26 45
Acceleration / deceleration time [ s ] 30 / 35 65 / 45 ( 55 / 45 ) 35 / 30 ( 25 / 30 )
Min temperature at nmax
relative to room temperature 23°C
< 0°C < 0°C < 0°C
Speed at 4°C [ rpm ] 15 000 12 000 8500
Aerosol-tight * yes yes yes
Autoclavable 121°C no 121°C
* Checked by CAMR, Porton-Down, UK
