Technical Data
73
Technical Data
Features specification
Ambient conditions
- indoor use
- maximum elevation 2000 m (6562 ft) above sea level
- max. relative humidity 80 % up to 31°C (88°F), linearly decreasing
down to 50 % relative humidity at 40°C (104°F).
Ambient temperature allowed +2 °C to +35 °C (36°F to 95°F)
run time - standard mode : 1min - 9 h 59 min, hold = permanent
- extended mode : 1min – 99 h, hold
maximum speed (n
max
) 15 000 rpm
(rotor-dependent, adjustable in steps of 10)
minimum speed (n
min
) 300 rpm
maximum RCF 21 885 (micro liter rotor)
maximum kinetic energy Legend™ T
Legend™ RT .
45.8 kNm (33 780 ft.lb)
54.8 kNm (40 418 ft.lb)
noise at maximum speed Legend™ T
Legend™ RT
< 66 dB (A)
< 55 dB (A)
(sound pressure level of emission according to DIN EN ISO 11 201)
Temperature set range -9 °C to +40 °C
