| Specim IQ User Manual | 60
Buttons
12 physical buttons
Display & keyboard 4.3” touch screen
Buzzer Indication sounds for the user
Usb connector USB Type-C
DIMENSIONS
Size 207 x 91 x 74 mm (depth with lens 125,5 mm)
Weight 1.3 kg
Spectral Camera Specifications
OPTICAL
F/number 1.7
Wavelength band 400 – 1000 nm
Magnification (Sensor / slit) 1/1.3
Straylight > 3 %
Keystone Corrected
Smile Corrected
Spectral resolution 7 mm
Input slit length 11.70 mm
Slit Height 42 µm
SENSOR
Sensor type CMOS
Number of pixels in active area (horizontal /
spatial)
512 pix
Number of pixels in active area (vertical / spectral) 204 pix
Active pixel pitch 17.58 µm
Data output 12 bit
QE peak >45 %
Full-well capacity >32000 e-
Peak SNR > 400 : 1
FORE OBJECTIVE
Object distance 100 - ∞ mm
Focal length 21 mm
F/number 2.2
Full field of view 39.7 deg
Full field of view at 1 m 0.5 x 0.5 m
