43
SEQUENCE
DWELL TIME
Set the dwell time of each, single channel display in sequential display
mode (3~60seconds)
SITE Select a channel to apply the name and covert settings change using the
mouse or the remote control.
Select a channel to apply the following settings using the mouse.
NAME Set the channel name. Press the right square button and set the channel
name and select OK using the mouse.
The name can be made up to 36 characters.
COVERT Enable/disable display of the specified video channel in live display.
COLOR TUNING
Brightness: Change the brightness value. (0~100)
Contrast: Change the contrast value(0~100)
Hue: Change the hue value(0~100)
Saturation: Change the saturation value(0~100)
VIDEO OUTPUT Select 1280x720 or 1920x1080.
4-6. Setup – NETWORK Mode
Select the NETWORK tab. Then, the network menu is displayed as pictured below. Navigate through the
menu items or change the settings using the mouse or the remote control.
Figure 4.6. NETWORK Setup Screen
