4-4. Setup – DEVICE Mode
In the SETUP menu, select the DEVICE tab. Then, the device menu is displayed as pictured below.
Navigate through the menu items or change the settings using the mouse or the remote control.
Figure 4.4. DEVICE Setup Screen
Table 4.4. Menu Items in DEVICE Setup Screen
Item Description
ALARM OUT
/ BEEP DURATION
Only one Alarm-out is available.
Set alarm dwell time from 5 to 60 seconds or infinite.
DIGITAL DETERRENT Setup schedule and audio recordings for Digital Deterrent.
CONTROLLER & PTZ Set the PTZ baud rate, protocol, and ID.
SPOT-OUT Display the channels triggered by an event (Refer to 4.4.4)
SITE Select specified channel for motion zone setup.
MOTION ZONE Select either Full Zone or Partial Zone for motion detection.
MOTION SENSITIVITY Set the motion sensitivity for the selected channel.
Control the motion sensitivity from 1 to 9.
(9 – Highest sensitivity, 1 – Lowest sensitivity)
KEY TONE Enable/disable key tone from front panel usage.
REMOTE CONTROL ID
