4-3. Setup – RECORD Mode
In the SETUP menu, select the RECORD tab. Then, the RECORD menu is displayed as pictured below.
Navigate through the menu items or change the settings using the mouse or the remote control.
Figure 4.3.1. RECORD Setup Screen
Table 4.3.1. Menu Items in RECORD Setup Screen
Menu Item Description
SITE Select a channel for applying the following settings using the mouse or the remote
control. To change the values of all channels, take the following steps. Select the
button to change the values of all channels.
RESOLUTION Select 960H, D1 or CIF for analog cameras using the mouse or the remote control.
FRAME RATE Set the frame rate for the specified channel. The sum of the frame rate values from
each channel cannot exceed the maximum frame rates for a specific recording
resolution.
