SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
Parameter Display Function
Possible parameter
setting
Unit
Factory
setting
P4._ MESSAGES
P4.0 TIME_OUT Control time out
Dead band time
limit
OFF, … 200 --- OFF
P4.1 POS_SW1 Position switch 1
Switching point
SW1
0.0 … 100.0 % 0.0
P4.2 POS_SW2 Position switch 2
Switching point
SW2
0.0 … 100.0 % 100.0
P4.3 SW1_ACTV
Switchpoint 1
enable
Active direction
SW1
FALL_BEL, EXCEED --- FALL_BEL
P4.4 SW2_ACTV
Switchpoint 2
enable
Active direction
SW2
FALL_BEL, EXCEED --- EXCEED
P4.5 EXIT Return
Return to
operating level
Function --- NV_SAVE
P5._ ALARMS
P5.0 LEAKAGE Leakage detection
Leakage to
actuator
ACTIVE, INACTIVE --- INACTIVE
P5.1 SP_ RGE
Setpoint rng
monitor
Outside the
setpoint range
ACTIVE, INACTIVE --- INACTIVE
P5.2 SENS_RGE
Sens. range
monitor
Operating range
exceeded
ACTIVE, INACTIVE --- INACTIVE
P5.3 CTRLER Controller monitor Controller inactive ACTIVE, INACTIVE --- INACTIVE
P5.4 TIME_OUT Control time out
Dead band time
limit
ACTIVE, INACTIVE --- INACTIVE
P5.5 STRK_CTR Stroke counter Movement counter ACTIVE, INACTIVE --- INACTIVE
P5.6 TRAVEL Travel counter Travel counter ACTIVE, INACTIVE --- INACTIVE
P5.7 EXIT Return
Return to
operating level
Function --- NV_SAVE
P6._ MAN ADJ
P6.0 MIN VR Min. valve range
Operating range,
min.
0.0 ... 100.0 % 0
P6.1 MAX VR Max. valve range
Operating range,
max.
0.0 ... 100.0 % 100
P6.2 ACTUATOR Actuator type Actuator type LINEAR, ROTARY --- LINEAR
P6.3 SPRNG Y2 Spring action (Y2) Spring action (Y2) CLOCKWISE, CTCLOCKWISE --- CTCLOCKWISE
P6.4 DANG DN Dead angle close Dead angle 0 % 0.0 ... 45.0 % 0.0
P6.5 DANG UP Dead angle open Dead angle 100 % 55.0 ... 100.0 % 100.0
P6.6 BOLT POS Bolt position Actuator position LEVER, STEM --- LEVER
P6.7 EXIT Return
Return to
operating level
Function --- NV SAVE
