15
IM-S51-07 CTLS Issue 1
SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
Parameter Display Function
Possible parameter
setting
Unit
Factory
setting
P7._ CTRL PAR
P7.0 KP UP KP value, up KP value (up) 0.1 ... 120.0 --- 5
P7.1 KP DN KP value, down KP value (down) 0.1 ... 120.0 --- 5
P7. 2 TVUP TVvalue, up lV value (up) 10 . . 450 --- 200
P7.3 TVDN TV value, down lV value (down) 10 ... 450 --- 200
P7.4 Y-OFS UP Y offset, up Y offset (up) 0.0 ... 100.0 % 48.0
P7.5 Y-OFS DN Y offset, down Y offset (down) 0.0 ... 100.0 % 48.0
P7.6 TOL BAND
Tolerance band
(zone)
Tolerance band
(zone)
0.3 ... 10.0 % 2.0
P7.7 DEADBAND Dead band Dead band 0.10 ... 10.00 % 0.20
P7.8 DB APPR
Deadband
Approach
Dead-band
approach
SLOW, MEDIUM, FAST MEDIUM
P7.9 TEST Test Test Function --- INACTIVE
P7.10 DB CALC Deadband calculat.
Dead-band
determination
ON, OFF --- ON
P7.11 LEAK SEN Leakage sensivity Leakage sensitivity 1 ... 7200 s 30
P7.12 CLOSE UP Pos. time out Position monitoring 0.0 ... 100.0 % 0.30
P7.13 EXIT Return
Return to operating
level
Function --- NV SAVE
P8._ ANLG OUT
P8.0 MIN RGE Min. range Min. current range 4.0 ... 18.4 mA 4.0
P8.1 MAX RGE Max. range Max. current range 20.0 ... 5.7 mA 20.0
P8.2 ACTION Action
Direction of action
of characteristic
curve
DIRECT, REVERSE --- DIRECT
P8.3 ALARM Alarm current Alarm message HIGH CUR, LOW CUR --- HIGH CUR
P8.4 RB_CHAR
Read back
character
Converted
characters
DIRECT, RECALC DIRECT
P8.5 TEST Test Test Function --- NONE
P8.6 ALR_ENAB Alarm function
Alarm via analog
output
ON, OFF --- ON
P8.7 CLIPPING
Current signal
enabled Signal
clipping range
Extension of signal
output to 3.8 ... 20.5
mA
4.0 ... 20.0; 3.8 ... 20.5 mA mA 4.0 ... 20.0
P8.8 EXIT Return
Return to operating
level
Function --- ---
