IM-S51-07 CTLS Issue 1
16
SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
Parameter Display Function
Possible parameter
setting
Unit
Factory
setting
P9._ DIG OUT
P9.0 ALRM LOG Alarm logic Alarm output logic ACTIVE HI, ACTIVE LO --- ACTIVE HI
P9.1 SW1 LOG Switchpoint 1 logic Logic SW1 ACTIVE HI, ACTIVE LO --- ACTIVE HI
P9.2 SW2 LOG Switchpoint 2 logic LogicSW2 ACTIVE HI, ACTIVE LO - - ACTIVE HI
P9.3 ALRM_DO Alarm Status Alarm Status ACTIVE, INACTIVE --- INACTIVE
P9.4 TEST Test Test
NONE, ALRM_ON, SW1_ON,
SW2_ON, ALL ON
--- NONE
P9.5 EXIT Return
Return to operating
level
Function --- NV SAVE
P10._ DIG IN
P10.0
FUNCTION
Function select
Function selection POS HOLD
NONE, POS_0 %, POS_100 %,
POS HOLD
--- NONE
P10.1 EXIT Return
Return to operating
level
Function --- ---
P11._ FS / IP
P11.0 FAIL POS Save position Safe position ACTIVE, INACTIVE --- INACTIVE
P11.1 FACT SET Factory setting Factory Setting Function --- NO F POS
P11.2 IP-TYP 1/P module type Type of 1/P module
NO_F_ POS, F_SAFE_1, F_
SAFE_ 2, F_ FREEZE1, F_
FREEZE2
--- [CUSTOM]
P11.3 IP_COM P IP compensation IP compensation ON, OFF --- ON
P11.4 HART REV HART revision HART Revision 5; 7 --- 5
P11.5 EXIT Return
Return to operating
level
Function --- NV SAVE
