14
Spohn + Burkhardt
4.5.2. Joystick VCS0 S1 – Ausführung mit Stulpenhalterrosette
Abbildung 6.
max. 2
96
85
Ø 81
4,5
85
Joystick VCS0 S1… – Maßbild (Maße in mm)
